Operating Guide | VLT® Decentral Drive FCD 302
Manual initialization erases all motor programming, localization, and monitoring data, and restores factory settings.
l
6.4.5 Initialization
6.4.5.1 Recommended Initialization
1.
Press [Main Menu] twice to access the parameter.
2. Scroll to parameter 14–22 Operation Mode and press [OK].
3.
Scroll to initialization and press [OK].
4.
Remove power to the unit and wait for the display to turn off.
Default parameter settings are restored during start-up. This may take slightly longer than normal.
5. Alarm 80, Drive initialized is shown.
6. To return to operating mode, press [Reset].
6.4.5.2 Manual Initialization
Manual initialization resets parameter settings except for the settings in:
Parameter 15-00 Operating Hours.
l
Parameter 15-03 Power Up.
l
Parameter 15-04 Over Temp.
l
Parameter 15-05 Over Volt.
l
1.
Remove power to the unit and wait for the display to turn off.
2. Press and hold [Status], [Main Menu], and [OK] simultaneously while applying power to the unit for approximately 5 s or until
hearing a click and the fan starts.
Factory default parameter settings are restored during start-up. The start-up process takes slightly longer than normal after
the manual initialization.
6.5 Basic Operational Programming
Drives require basic operational programming before running for the best performance. Basic operational programming requires
entering motor nameplate data for the motor being operated and the minimum and maximum motor speeds. Enter the data in
accordance with the following procedure. Enter the data with power ON, but before operating the drive.
1.
Press [Quick Menu] on the LCP.
2. Use the navigation keys to scroll to Q2 Quick Setup and press [OK].
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Figure 30: Quick Menus
3.
Select language and press [OK].
44 | Danfoss A/S © 2025.04
0.75A 1 (1)
Operating the Drive
AQ267036816112en-000301 / 130R0208
