3 Mechanical Installation
3.1 Recommended Tools and Equipment
Table 4: Tools and Equipment
Equipment
Screwdrivers
Socket (Hex)
Slotted
Slotted/torx
Spanner
(1)
LCP
(2)
LCP cable
1) Code number 130B1078.
2) Code number 130B5776.
3.2 Installation Environment
REDUCED LIFETIME
In environments with airborne liquids, particles, or corrosive gases, ensure that the IP/Type rating of the equipment matches the
installation environment. Failure to meet requirements for ambient conditions can reduce the lifetime of the drive.
Ensure that requirements for air humidity, temperature, and altitude are met.
l
Vibration and shock
The drive complies with requirements for units mounted on the walls and floors of production premises, and in panels bolted to walls or
floors. For detailed ambient conditions, refer to
3.3 Cooling Requirements
OVERHEATING
Improper mounting can result in overheating and reduced performance.
Install the drive following the installation and cooling requirements.
l
The VLT® Decentral Drive FCD 302 has no forced cooling. It relies only on natural convection for cooling using the cooling fins.
Provide a minimum of 100 mm (4 in) top and bottom air cooling clearance during installation, as shown in
l
Derating starts above 40 °C (104 °F) and 1000 m (3280 ft) elevation above sea level. See the VLT® Decentral Drive FCD 302 Design Guide
l
for detailed information.
Danfoss A/S © 2025.04
Size
–
8 mm
0.4x2.5 mm
1.0x5.5 mm/TX20
19, 24, 28 mm
–
–
NOTICE
7.4 Ambient Conditions.
NOTICE
Description
–
For fastening inverter screws/mounting of brackets
For spring loaded power and control terminals
For cable clamps inside the installation box
For blind-plugs
Local control panel
Connection cable for local control panel
AQ267036816112en-000301 / 130R0208 |
Mechanical Installation
Figure 8.
19
