Operating Guide | VLT® Decentral Drive FCD 302
5.5 Connection of Sensors/Actuators on M12 Sockets
Table 12: Connection Input (4 x M12)
Pin
1
3
4
Table 13: Connection Output (2 x M12)
Pin
1
3
4
1) When reserved wires for option are used. If not used, they can be cut off.
LCP
USB
Figure 25: Connection of Sensors/Actuators on M12 Sockets
5.6 DIP Switches
Analog input terminals 53 and 54 can select either voltage (0–10 V) or current (0–20 mA) input signals.
l
Set switch S201 terminal 53 to select the signal type: ON=current, OFF=voltage.
l
Set switch S202 terminal 54 to select the signal type: ON=current, OFF=voltage.
l
Terminal 53 (default) is for a speed reference in an open loop.
l
Terminal 54 (default) is for a feedback signal in a closed loop.
l
1
3
Figure 26: Location of DIP Switches
Danfoss A/S © 2025.04
Wire color
Brown
Blue
Black
Wire color
Brown
Blue
Black
RL2 RL1 33
FB2 FB1
18 19 32
2
4 5
Terminal
12
20
18, 19, 32, 33
Terminal
(1)
Reserved
20
02, 05
AQ267036816112en-000301 / 130R0208 |
Controls and Options Installation
Function
+24 V
0 V
Digital input
Function
Reserved
0 V
N.O. (24 V)
