Operating Guide | VLT® Decentral Drive FCD 302
2 Receiving the Drive
2.1 Verifying the Shipment and the Contents
The packaging contains:
Accessories bag, supplied only with order of installation box.
l
The accessories bag contains:
2 cable clamps.
¢
Bracket for motor/loads cables.
¢
Elevation bracket for cable clamp.
¢
Screw 4 mm, 20 mm.
¢
Thread forming 3.5 mm, 8 mm.
¢
Operating Guide.
l
Drive.
l
Based on the installed options, the box includes either 1 or 2 bags and 1 or more booklets.
Make sure that the items supplied and the information on the nameplate correspond to the order confirmation.
l
Decentral Drive
VLT®
www.danfoss.com
1
T/C: FCD302P1K5T4W66H1X1XMFCFXXXXA0BXXXXXXDX
2
P/N: 131Z5118 S/N: 000000G000
4
1.5kW(400V) / 2.0HP(460V)
5
IN: 3x380-480V 50/60Hz, 3.7/3.1A
6
OUT: 3x0-Vin 0-590Hz, 4.1/3.4A
7
IP66 Enclosure Tamb. 40 ˚C/104 ˚F
9
Figure 5: Example of the Model Code on the Product Nameplate
1 Type code
3 Serial number
5 Input voltage, frequency, and current (at low/high
voltages)
7 Enclosure type and protection rating (IP)
9 Certifications
WARRENTY
Removing the nameplate from the drive can result in the loss of warranty.
l
Visually check the packaging and the drive for damage caused by inappropriate handling during shipment. File any claim for damage
with the carrier. Retain damaged parts for verification. The drive is shipped with a selection of loose components packed in plastic bags.
The amount of these components depend on the enclosure size and product configuration.
