Operating Guide | VLT® Decentral Drive FCD 302
1 Graphical display with status lines.
3 Navigation keys and indicator lights.
a Status line: Status message showing icons and graphics.
c Status line: Status messages showing text.
The LCP display can show up to 5 items of operating data while showing Status.
If start-up is delayed, the LCP shows the INITIALIZING message until it is ready. Adding or removing options can delay the start-up.
6.4.2 Uploading and Downloading Data with the LCP
1.
Press [Off] to stop the motor before uploading or downloading data.
2. Press [Main Menu].
3.
Go to parameter 0–50 LCP Copy and press [OK].
4.
Select [1] All to LCP to upload data to the LCP, or select [2] All from LCP to download data from the LCP.
5. Press [OK].

A progress bar shows the status of the data upload or download process.
6.
To return to normal operation, press [Hand On] or [Auto On].
6.4.3 Changing Parameter Settings
Parameter settings can be accessed and changed via the [Quick Menu] or [Main Menu] keys. The Quick Menu only gives access to a limited
number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
2.
Press [▲] [▼] to browse through the parameter groups, press [OK] to select a parameter group.
3.
Press [▲] [▼] to browse through the parameters, press [OK] to select a parameter.
4. Press [▲] [▼] to change the value of a parameter setting.
5. Press [◄] [►] to shift digit when a decimal parameter is in the editing state.
6.
Press [OK] to accept the change.
7.
Press either [Back] twice to enter Status, or press [Main Menu] once to enter the Main Menu.
6.4.4 Restoring Default Settings
RISK OF DATA LOSS
When restoring default settings, there is a risk of losing programming, motor data, localization, and monitoring records.
Provide a back-up by uploading data to the LCP before initialization.
l
Restoring the default parameter settings is done by initialization of the drive. Initialization is carried out via parameter 14-22 Operation
Mode (recommended) or manually.
Initialization via parameter 14-22 Operation Mode does not reset the drive settings such as hours run, serial communication
l
selections, personal menu settings, fault log, alarm log, and other monitoring functions.
Danfoss A/S © 2025.04
2 Menu keys and indicator lights - changing parameters and
switching between display functions.
4 Operation keys and indicator lights.
b Line 1–2: Operator data lines showing data defined or
selected. Add up to 1 extra line by pressing [Status].
NOTICE
NOTICE
Operating the Drive
AQ267036816112en-000301 / 130R0208 | 43
