Operating Guide | VLT® Decentral Drive FCD 302
100 (4)
100 (4)
100 (4)
100 (4)
Figure 8: Top and Bottom Cooling Clearance
3.4 Mounting the Drive
3.4.1 Installation Requirements for the Drive
The VLT® Decentral Drive FCD 302 consists of 2 parts.
1
2
Figure 9: VLT® Decentral Drive FCD 302 Small/Large Unit
1
Inverter part
Install the installation box and inverter part according to the allowed mounting positions:
For standard applications, see
l
For hygienic applications, see
l
20 | Danfoss A/S © 2025.04
Figure 10.
Figure 11.
1
2
2
Installation box
Mechanical Installation
