Operating Guide | VLT® Decentral Drive FCD 302
POTENTIAL EQUALIZATION
There is a risk of burst transient when the ground potential between the drive and the control system is different.
Install equalizing cables between the system components. Recommended cable cross-section: 16 mm
l
1
Figure 17: PE Connection
1 PE connection between installation box/inverter part
The external grounding terminal is available as an accessory (code number 130B5833).
4.5 Terminals Overview
4.5.1 Terminal Locations
5
13
Figure 18: Terminal Location (Small Unit)
Danfoss A/S © 2025.04
NOTICE
4 2 1 3 11
7 8 13 9 10
2
12
AQ267036816112en-000301 / 130R0208 |
Electrical Installation
(6 AWG).
6
13
