Pin No. Pin Name
1 PA8
2 PB1
3 PB2
J0204
Pin No. Pin Name
1 PB5
2 PC3
3 PC2
4 PB8
5 PC1
J0205
Pin No. Pin Name
1 GND
2 PA13
3 PA14
4 RESET_N
5 VDD_3V3
J0206
Pin No. Pin Name
1 PA4
2 PA5
3 PA6
4 PA7
5 GND
J0207
KG200Z_TE-B_User_Guide
Description
Connected directly to GPIO8 of the module
Connected directly to GPIO15 of the module
Connected directly to GPIO16 of the module
Description
Connected directly to GPIO19 of the module
Connected directly to GPIO33 of the module
Connected directly to GPIO32 of the module
Connected directly to GPIO22 of the module
Connected directly to GPIO31 of the module
Description
Ground
Serial wire debug input/output
Serial wire debug clock
Reset the module
3.3 V power supply
Description
Connected directly to GPIO4 of the module
Connected directly to GPIO5 of the module
Connected directly to GPIO6 of the module
Connected directly to GPIO7 of the module
Ground
