Figure 24: Complete Firmware Upgrade in Bootloader Mode
6. Once the firmware upgrade is complete, connect the BOOT pin to the GND on J0111 (BOOT header)
to reset the module and enter into normal operation.
Figure 25: Jumpers on J0111 in Normal Operating Mode
KG200Z_TE-B_User_Guide
31 / 34
