Pin No. Pin Name
1 PC0
2 PC5
3 PC4
4 PC6
5 GND
J0208
Pin No. Pin Name
1 PA0
2 PA1
3 PB6
4 PB7
5 GND
J0209
Pin No. Pin Name
1 PB10
2 PB11
3 PB12
4 PB13
5 GND
4.8. ST-LINK Connector
KG200Z-TE-B provides an ST-LINK connector (J0201), which is connected to the GPIO12 and GPIO13
of the module for downloading firmware and debugging.
KG200Z_TE-B_User_Guide
Description
Connected directly to GPIO30 of the module
Connected directly to GPIO35 of the module
Connected directly to GPIO34 of the module
Connected directly to GPIO36 of the module
Ground
Description
Connected directly to GPIO0 of the module
Connected directly to GPIO1 of the module
Connected directly to GPIO20 of the module
Connected directly to GPIO21 of the module
Ground
Description
Connected directly to GPIO24 of the module
Connected directly to GPIO25 of the module
Connected directly to GPIO26 of the module
Connected directly to GPIO27 of the module
Ground
