Interface Applications
This chapter outlines the information and applications of some hardware interfaces of KG200Z-TE-B.
4.1. Power Supply Interfaces
KG200Z can be powered by J0102 (USB Type-C power supply interface) or J0104/J0105 (2-pin header).
The simplified schematic of KG200Z-TE-B is shown in the following figure.
J0102
USB Type-C
J0104/J0105
Pin Header
4.2. Power Switch and Reset Button
KG200Z-TE-B includes one power switch (S0101) and one reset button (S0102) as shown in the following
figure.
KG200Z_TE-B_User_Guide
U0102
5 V
LDO
Figure 6: Power Supply for KG200Z-TE-B
Short-Range Module Series
3.3 V
USB-to-UART
U0103
KG200Z
U0101
Bridge
