4.7. Test Points
KG200Z-TE-B features a series of test points, which can help you to obtain the corresponding waveform
of some signals.
J0108, J0203, J0206, J0208, J0209, J0202, J0110, J0109, J0106, J0107, J0101, J0207, J0204, J0205
are illustrated in the following figures.
Table 4: Description of Test Points
J0108
Pin No.
Pin Name
1
VDD_3V3
2
VDD_3V3
J0203
KG200Z_TE-B_User_Guide
Figure 14: Test Points
Description
3.3 V power supply
3.3 V power supply
Short-Range Module Series
19 / 34
