Quectel Short-Range Module Series User Manual page 24

Table 6: Description of Status LEDs
RefDes.
D0102
D0104
D0201
D0202
D0203
D0204
D0205
KG200Z_TE-B_User_Guide
Figure 16: Status LEDs
Description
Indicates the power status of U0101
Light on: high level
Light off: low level
Indicates the power status of the module's VBAT
Light on: high level
Light off: low level
Indicates the power status of the module's GPIO29
Light on: high level
Light off: low level
Indicates the power status of the module's GPIO11
Light on: high level
Light off: low level
Indicates the power status of the module's GPIO18
Light on: high level
Light off: low level
Indicates the power status of the module's GPIO28
Light on: high level
Light off: low level
Indicates the power status of the module's GPIO23
