Short-Range Module Series
Figure 12: LPUART Headers
4.6. RF Connector
KG200Z-TE-B is equipped with a RF SMA connector (J0103), designed for connecting to the module's
ANT_LORA.
The simplified schematic of RF connection is shown in the following figure.
KG200Z
J0103
ANT_LORA
SMA
Figure 13: RF Connection
KG200Z_TE-B_User_Guide
18 / 34
