KG200Z
GPIO2
GPIO3
4.4. BOOT Header
KG200Z-TE-B features a BOOT header (J0111) as shown below.
4.5. LPUART Headers
KG200Z-TE-B has two LPUART headers (J0112 and J0113), which are connected to the module's GPIO2
and GPIO3 respectively with the jumpers as shown below.
KG200Z_TE-B_User_Guide
U0101
3.3 V I/O
USB-to-UART
Bridge
Figure 10: USB-to-UART Connection
Figure 11: BOOT Header
Short-Range Module Series
J0102
USB Type-C
17 / 34
