Regency P33S-NG Owners & Installation Manual

P33 sunrise gas fireplace
Table of Contents

Advertisement

Quick Links

Regency P33 Sunrise
www.regency-fi re.com.au
WARNING:
If the information in these instructions are not followed exactly,
a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
918-803
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Installation Manual
MODELS: P33S-NG
LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AS4558,
NZS 5262 and have been certifi ed
by the Australian Gas Association for
installation and operation as described
in these Installation and Operating
Instructions.
Your unit should be serviced
annually by an authorised service
person.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fi re department.
Owners &
P33S-LP
P33S-ULPG
07/08/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P33S-NG and is the answer not in the manual?

Questions and answers

Summary of Contents for Regency P33S-NG

  • Page 1 Regency P33 Sunrise ™ Owners & Installation Manual Gas Fireplace MODELS: P33S-NG P33S-LP P33S-ULPG LISTINGS AND CODE APPROVALS These gas appliances have been tested in accordance with AS4558, NZS 5262 and have been certifi ed by the Australian Gas Association for...
  • Page 2 As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment ® now to acquaint yourself with these instructions and the many features of your Regency Fireplace. Regency P33 Sunrise...
  • Page 3: Table Of Contents

    Optional Remote Control ..........32 Wall Switch ..............32 Aeration Adjustment ............33 Wiring Diagram ............33 Optional Stainless Steel ..........34 Refl ective Panel Installation ........34 Glass Crystal Installation On Burner ......35 Optional pebble Installation On fi rebox base ....35 Regency P33 Sunrise Gas Fireplace...
  • Page 4: Data Badge

    DATA BADGE DATA BADGE NOTE: Regency ® units are constantly being improved. This is a copy of the label that accompanies each P33 Gas Fireplace. We have printed a copy of the contents here for your review. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
  • Page 5: Dimensions

    DIMENSIONS UNIT DIMENSIONS Regency P33 Sunrise Gas Fireplace...
  • Page 6: Installation

    9) Wear gloves and safety glasses for protection CIALLY THE FIREPLACE GLASS, AND while doing required maintenance. SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. 10) Be aware of electrical wiring locations in walls and ceilings when cutting holes for termination. Regency P33 Sunrise Gas Fireplace...
  • Page 7: Installation Checklist

    Flat on Wall Corner Recessed into Wall/Alcove 11) Final check. Corner Before leaving this unit with the customer, the installer must ensure that the appliance is fi ring correctly and operation fully explained to customer. Regency P33 Sunrise Gas Fireplace...
  • Page 8: Clearances

    Vertical (Rigid) 1-1/4" 32mm D: Alcove Width 48" (1219mm) Sidewall to Sidewall (Minimum) E: Alcove Depth 36" (914mm) Front to Back Wall (Maximum) *Note: All measurements are from the top/side of the unit, not from facade. Regency P33 Sunrise Gas Fireplace...
  • Page 9: Mantel Clearances

    0” - 3-1/2" (89mm) 11"(279mm) 9"(229mm) 7"(178mm) Top of Side View 41"(1041mm) Unit to floor or 29”(737mm) to base of unit MANTEL LEG CLEARANCES Combustible mantel leg clearances from side of unit as per diagram: Regency P33 Sunrise Gas Fireplace...
  • Page 10: Framing & Finishing

    fl ame package, carbon, blue fl ames etc. These are not product related issues. Regency P33 Sunrise Gas Fireplace...
  • Page 11: Framing Dimensions

    36" (914mm) Rigid 32" (812mm) Flex Vent Centerline Height* 30" (762mm) Rigid 26" (660mm) Flex Gas Connection Height* 1 1/2" (38mm) Gas Connection Inset* 4" (102mm) Gas Connection Width* 3" (76mm) * Measured from base of unit. Regency P33 Sunrise Gas Fireplace...
  • Page 12: Unit Assembly Prior To Installation

    ® There are 5 vent systems approved for use with the P33S: the Regency Direct Vent Flex System for Horizontal Terminations only and the Simpson Dura-Vent, Selkirk Direct-Temp, Amerivent Direct Vent and Security Secure Vent Systems for Horizontal and Vertical Terminations (see following "Venting"...
  • Page 13: Exterior Flue Termination Locations

    (IV) A fl ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free fl ow of air at the appliance is achieved. Regency P33 Sunrise Gas Fireplace...
  • Page 14: Regency ® Direct Vent Fl Ex System

    #8 x 1-1/2" drill point, stainless steel (4) Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency ® may be used for Flex installations. MINIMUM MINIMUM RIGID PIPE CENTER-LINE FLEX KIT CENTER-LINE Note: - Unit must be raised by 1".
  • Page 15: Rigid Pipe Venting Systems

    American Metal Products Ameri Vent Direct Vent, Security Secure Vent ® , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency P33 Sunrise Gas Fireplace...
  • Page 16: 4" X 6-5/8" Rigid Pipe Cross Reference Chart

    Offset Support 46DVA-ES (N/A - FPI) 4DT-OS SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA Regency P33 Sunrise Gas Fireplace...
  • Page 17 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency P33 Sunrise Gas Fireplace...
  • Page 18: Rigid Pipe Venting Arrangements

    Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles. • Vent must be supported at offsets. Note: Must use optional rigid pipe adapter when using rigid vent systems (Part # 510-994). Regency P33 Sunrise Gas Fireplace...
  • Page 19: Venting Arrangements - Vertical Terminations

    The shaded area in the diagrams show the allowable vertical terminations. Horizontal Distance (Feet) Horizontal Distance (Feet) Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. "THIS UNIT MUST ALWAYS TERMINATE / VENT DIRECTLY TO THE OUTDOORS." Regency P33 Sunrise Gas Fireplace...
  • Page 20: Horizontal Terminations

    Firestops are required at each fl oor level and whenever passing through a wall. 2’ (0.6m) Minimum Minimum Simpson Dura-Vent Center-Line Flex Kit Center-Line Horizontal (Feet) Horizontal (Feet) Max. 24"(0.6m) Max. 24"(0.6m) "THIS UNIT MUST ALWAYS TERMINATE / VENT DIRECTLY TO THE OUTDOORS." Regency P33 Sunrise Gas Fireplace...
  • Page 21 .9m Max. 1.2m Min. 1.8m Max. 2.4m total vertical 1.2m Max. 1.8m Min. 2.1m Max. and max. 2.4m total horizontal. 1.5m Max. 2.4m Min. 2.4m Max. Please note minimum .3m between 90 elbows is required. Regency P33 Sunrise Gas Fireplace...
  • Page 22 1.5m Min. 2.4m Max. 1.8m Min. required. 1.8m Max. 1.8m Min. Please note minimum .3m between 90 elbows is required. For additional vertical venting with 2 x 90 elbows, refer to "Rigid Pipe Venting Arrangements" Section. Regency P33 Sunrise Gas Fireplace...
  • Page 23 1.5m Min. 1.8m Max. 2.4m Min. Please note minimum . 3 m b e t w e e n 9 0 1.8m Min. 2.1m Max. 2.7m Min. elbows is required. 2.7m Min. 2.4m Max. 3m Min. Regency P33 Sunrise Gas Fireplace...
  • Page 24: Unit Installation With Horizontal Termination

    7) Before connecting the horizontal run of vent result in drafting or performance issues not pipe to the vent termination, slide the Wall covered under warranty. Silicone (red RTV) Thimble (Part # 620-926) over the vent pipe. is optional. Regency P33 Sunrise Gas Fireplace...
  • Page 25: Unit Installation With Vertical Termination

    7) Ensure vent is vertical and secure the base of the fl ashing to the roof with roofi ng rails, Diagram 2 slide storm collar over the pipe section and seal with a mastic. Regency P33 Sunrise Gas Fireplace...
  • Page 26: Pilot Adjustment

    INSTALLATION PILOT ADJUSTMENT GAS PIPE PRESSURE P33S-NG System Data TESTING Periodically check the pilot fl ames. Correct For 0 to 1372m altitude fl ame pattern has three strong blue fl ames: Burner Inlet Injector Sizes: The appliance must be isolated from the gas 1 fl...
  • Page 27: Conversion From Ng To Lpg

    Firebox base Reinstall new burner orifi ce LPG stamped #56 and tighten. 5) Pull off the pilot cap to expose the pilot orifi ce. (Diagram 5) Diagram 1 Pilot Orifi ce Pilot Cap Diagram 5 Regency P33 Sunrise Gas Fireplace...
  • Page 28 12) Check that the screw is clean and if necessary remove dirt. 13) Flip the screw (Fig. 3). Fig. 6 WARNING! Also check that the pilot and main burner injectors Fig.3 are appropriate for the gas type. Regency P33 Sunrise Gas Fireplace...
  • Page 29: Conversion From Ng To Ulpg

    Burner Assembly to the fi rebox base. Diagram 6 Lift out the burner assembly. Burner Orifi ce (See Diagrams 1 & 2) Reinstall new burner orifi ce LPG stamped # and tighten. Pilot Orifi ce Pilot Cap Diagram 4 Diagram 1 Regency P33 Sunrise Gas Fireplace...
  • Page 30 11) Check that the screw is clean and if necessary remove dirt. 12) Flip the screw (Fig. 3). Fig. 6 WARNING! Also check that the pilot and main burner injectors Fig.3 are appropriate for the gas type. Regency P33 Sunrise Gas Fireplace...
  • Page 31: Dc Spark Box Battery Replacement

    (Diagram 5) Diagram 2 5) Reinstall battery cover on DC Spark Box. 6) Reinstall faceplate (refer to steps 5 and 6 of Faceplate installation P. 39). Diagram 5 6) Replace DC Spark Box and reverse steps. Regency P33 Sunrise Gas Fireplace...
  • Page 32: Optional Wall Thermostat

    REMOTE CONTROL 1) Run the supplied wire through the right or left side gas inlet opening. Be careful not ® Use the Regency Remote Control Kit approved to damage wire. A wall thermostat may be installed if desired, for this unit. Use of other systems may void connect the wires as per the wiring diagram.
  • Page 33: Aeration Adjustment

    "S.I.T" Valve (To THTP) (To TH) ON OFF Remote Receiver Remote Transmitter or Thermostat (Optional) (Millivolt) (Optional) 909-128 CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency P33 Sunrise Gas Fireplace...
  • Page 34: Optional Stainless Steel

    4) With the top panel in place - install back panel. The back panel fi ts under the top panel, push the top panel up to fi t back panel into position. (Diagrams 3) Diagram 3 Back Panel Regency P33 Sunrise Gas Fireplace...
  • Page 35: Glass Crystal Installation On Burner

    Blue Glass Crystals or optional Ceramic Spa Stones. NOTE: Only the supplied and approved pebbles are to be used. Use of any other type of pebbles or material can create a danger and will void warranty. Regency P33 Sunrise Gas Fireplace...
  • Page 36: Glass Door Installation

    Repeat for 2nd spring. See diagram 3. To remove the fl ush door, reverse the above steps. Diagram 3 To remove the fl ush door, reverse the above steps. Regency P33 Sunrise Gas Fireplace...
  • Page 37: Screen Installation

    3) With screen in position, secure to the faceplate with 3 x #8 self tapping screws (as shown below). 5) Faceplate shown below with screen installed. To install faceplate, follow the faceplate installation instructions on the next page. Regency P33 Sunrise Gas Fireplace...
  • Page 38: Faceplate Installation

    2) Install the heat defl ector on the fi re box as shown in Diagrams 2 & Loosen 3 Phillips head screws already in fi rebox, slide heat defl ector on to screws and retighten. Diagram 4 Heat Defl ector Top of Firebox Diagram 2 Regency P33 Sunrise Gas Fireplace...
  • Page 39 6) Hook the fl ange on the faceplate over the top of the fl ush door and gently lower the faceplate into place until it rests against the faceplate supports as shown in Diagrams 7 & 8. Diagram 9 Diagram 7 Faceplate Support Faceplate Regency P33 Sunrise Gas Fireplace...
  • Page 40: Operating Instructions

    Use a non-abrasive 3) Turn the gas control knob to the "OFF" posi- cleaner and DO NOT ATTEMPT TO CLEAN tion to turn off the pilot. THE GLASS WHILE IT IS HOT. Regency P33 Sunrise Gas Fireplace...
  • Page 41: Copy Of Lighting Plate Instructions

    OPERATING INSTRUCTIONS COPY OF LIGHTING PLATE INSTRUCTIONS Regency P33 Sunrise Gas Fireplace...
  • Page 42: Maintenance

    3) Check for evidences of excessive * The use of substitute glass will void all product ® resistant paint. Regency uses StoveBright condensation, such as water droplets forming warranties. Paint - Metallic Black #6309.
  • Page 43: Valve Tray Replacement

    9) Remove the 10 Phillips head screws securing the valve tray assembly in place (diagram 4) and then lift the entire assembly out (Diagram 10) Undo the pilot tube from the valve with a 11mm (7/16") wrench. Diagram 6 Diagram 4 Regency P33 Sunrise Gas Fireplace...
  • Page 44: Trouble Shooting Guide

    A low setting on the pilot Examine the pilot and as necessary adjust the pilot fl ame. (Gas:9) pilot fl ame fl ame, can result in a will not ignite. failure to ignite due to low pressure. Regency P33 Sunrise Gas Fireplace...
  • Page 45 An oversized orifi ce and/ Verify the orifi ce size and replace if necessary. Test and correct inlet pressure as necessary (Gas:14). or high gas pressure will cause overfi ring and carboning. Regency P33 Sunrise Gas Fireplace...
  • Page 46: Parts List

    Bumper Rubber W/Machine Screw 8-32 x 3/8" 434-032 Control Shield 904-925 Cap Assy Brushed Stainless 3/4" diameter. 948-247 Door Handle 434-018F Heat Defl ector 14) 434-519 Control Mounting Plate 918-803 Manual Not available as a replacement part. Regency P33 Sunrise Gas Fireplace...
  • Page 47: Warranty

    Regency shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products.
  • Page 48 Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency Sunrise is a trademark of FPI Fireplace Products International Ltd. © Copyright 2009, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada Regency P33 Sunrise Gas Fireplace...
