Altronix NetWay Spectrum NetWay4EBT3 Series Installation Manual page 4

Parameter Description
Number of Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each.
Ports IEEE 802.3af, 802.3at, 802.3bt compliant. One (1) Gigabit SFP Port.
Input Power
115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
Requirements
Operating Ambient Temperature:
Environmental
Conditions Storage Temperature: – 30ºC to 85ºC (– 22ºF to 185ºF)
Relative Humidity:
Operating Altitude:
Weights
(approx.)
Fig. 1
- 4 -
Technical Specifications:
360W: – 30ºC to 70ºC (– 22ºF to 158ºF)
240W: – 30ºC to 75ºC (– 22ºF to 167ºF)
85%, +/– 5%
– 304.8 to 2,000m
Model
NetWay4EBTWP3
NetWay4EBTWPX3
NetWay4EBTX3
NetWay4EBTPL3
Typical Applications:
To 48V Stand-by
L G N
115/230VAC
Input
Product Weight
10.5 lb. (4.76 kg)
15 lb. (6.8 kg)
6.65 lb. (3.02 kg)
2.6 lb. (1.18 kg)
Batteries
USB Port for
Configuring
Cable Guide
Separate
Inlets
IP Device
(802.3af / 802.3at / 802.3bt)
IP Device
(802.3af / 802.3at / 802.3bt)
Shipping Weight
11.9 lb. (5.4 kg)
17.5 lb. (7.9kg)
7.55 lb. (3.42kg)
4.0 lb. (1.81kg)
Fig. 1a
Master Reset
IP Device
(802.3af / 802.3at / 802.3bt)
IP Device
(802.3af / 802.3at / 802.3bt)
Netway4EBT3 Series Installation Guide
Fiber to
Switch
