Altronix NetWay Spectrum NetWay4EBT3 Series Installation Manual page 2

Altronix NetWay4EBT3 Series Hardened 802.3bt 4PPoE Switches are equipped with one (1) 1Gb SFP port and four
(4) POE IEEE802.3af/3at/3bt PoE ports rated at 90W each, with a 360W total power. Embedded LINQ Technology
enables monitoring, control, and reporting from anywhere over the network.
For unmanaged switches, refer to NetWay4E1BT3 Series.
Agency Listings:
• CE European Conformity.
Input:
• 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
Power Output:
• Four (4) 10/100/1000 Mbps Ethernet ports rated at
90W each (360W total power).
• IEEE 802.3af, 802.3at, 802.3bt compliant.
SFP Ports:
• One (1) Gigabit SFP port.
Ethernet Ports:
• Four (4) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher structured cable.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
Battery Backup
• 48VDC charging circuit charges
sealed lead acid* or gel type* batteries.
• Automatic switch over to stand-by battery
when AC fails.
Indicators (LED):
• Individual PoE On LEDs for each port.
• Individual IP Link status, 10/100 Base-T/active
LEDs for each port.
• ALOS LED indicates fiber connection for SFP port.
• Heartbeat LED indicates proper operation of the unit.
VLAN:
• Multiple management VLAN assignment.
• 802.1Q Tagged VLAN.
• Up to 10 VLAN groups. ID Range 2-4095.
*CAUTION: When using lead acid or gel type batteries, enclosure must be properly ventilated.
Battery operational temperature should be derated 10-15ºC lower than manufacture's rated high temperature.
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 For use with Single-Mode Fiber for distances up to 10km.
P1AB2K For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE For use with CAT5e or better for distances up to 100m.
- 2 -
Recommended Altronix SFP Modules:
Overview:
Features:
LINQ Technology:
• Remote network management allows for camera/
device reset and diagnostic monitoring.
• Provides local and/or remote access to critical
information via LAN/WAN.
• Email and Windows Dashboard Alert notifications
report real-time events.
• Event log tracks history.
Mechanical:
NetWay4EBTPL3:
• Dimensions (H x W x D approx.):
10.75" x 8.875" x 2.375"
(273.1mm x 225.4mm x 60.3mm).
NetWay4EBTWPX3:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates sealed lead acid or gel type
12VDC batteries.
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
NetWay4EBTWP3:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWay4EBTX3:
• NEMA1 Rated enclosure for indoor use
• Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 83mm).
Netway4EBT3 Series Installation Guide
