4" Standard Pump Installation, Operation & Service Manual
Control Boxes
Item
(Ref. Figure 42)
Item
(Ref. Figure 42)
1
Electrical
Continuous
interlock
duty capacitor
R
Extractable
B
packer
O
G
Junction box
in manifold
Internal
overload
protector
Motor
STP
Figure 42. 880-041-5/880-042-5 Control Box
Table 11. 880-041-5 Control Box W/115V Coil (60 Hz)
Part No.
1 108-572-4
2 147-006-1
3 014-723-1
4 080-858-1
5 008-202-1
Table 12. 880-042-5 Control Box W/230V Coil (50/60 Hz)
Part No.
1 108-572-4
2 147-006-1
3 014-720-1
4 080-858-1
5 008-202-1
5
Description
Control box
Pilot light ass'y
Line contractor relay
Toggle switch
Terminal block
Description
Control box
Pilot light ass'y
Line contractor relay
Toggle switch
Terminal block
51
Control Boxes
3
4
153-15.eps
Qty.
1
1
1
1
1
Qty.
1
1
1
1
1
