4" Standard Pump Installation, Operation & Service Manual
Specifications
Table 2 shows the adjustable pump lengths by model number
Table 2. Distance From Eye Bolt To Inlet
COMPRESSED
MODEL# in
P33R1T1 68.5
P33R1T2 91.5
P33R1T3 125.5
P33R1T4 125.5
P75S1T1 71.0
P75S1T2 94.0
P75S1T3 128.0
P75S1T4 128.0
P150S1T1 73.5
P150S1T2 96.5
P150S1T3 130.5
P150S1T4 130.5
X3P150S1T1 74.5
X3P150S1T2 97.5
X3P150S1T3 131.5
X3P150S1T4 131.5
P75S3-3T1 73.0
P75S3-3T2 96.0
P75S3-3T3 130.0
P75S3-3T4 130.0
P150S3-3T1 75.0
P150S3-3T2 98.0
P150S3-3T3 132.0
P150S3-3T4 132.0
X4P150S3T1 75.5
X4P150S3T2 98.5
X4P150S3T3 132.5
X4P150S3T4 132.5
P75S17-3T1 72.0
P75S17-3T2 95.0
P75S17-3T3 129.0
P75S17-3T4, 129.0
P150S17-3T1 74.0
P150S17-3T2 97.0
P150S17-3T3 131.0
P150S17-3T4 131.0
EXTENDED
mm in mm
1740 95.5 2426
2324 125.5 3188
3188 192.5 4890
3188 159.5 4051
1803 98.0 2489
2387 128.0 3251
3251 195.0 4953
3251 162.0 4115
1865 100.5 2551
2450 130.5 3313
3313 197.5 5015
3313 164.5 4177
1887 101.5 2573
2471 131.5 3335
3335 198.5 5037
3335 165.5 4199
1853 100.0 2539
2437 130.0 3301
3301 197.0 5003
3301 164.0 4165
1907 102.0 2592
2491 132.0 3354
3354 199.0 5056
3354 166.0 4218
1920 102.5 2606
2504 132.5 3368
3368 199.5 5073
3368 166.5 4232
1828 99.0 2514
2412 129.0 3276
3276 196.0 4977
3276 163.0 4139
1878 101.0 2564
2462 131.0 3326
3326 198.0 5028
3326 165.0 4189
