4" Standard Pump Installation, Operation & Service Manual
Installing a Replacement Extractable Pump
When servicing unit use non-sparking tools and use caution when removing or installing
equipment to avoid generating a spark.
IF FIXED LENGTH, SKIP TO STEP 9.
1. If a ball valve is installed down line from the pump, close it.
2. Remove existing Red Jacket pump - see "Removing the Pump" on page 33.
Confirm length of pump prior to installation.
Do not damage the surface above the discharge port. The o-ring below the leak
detector port seals on this surface.
3. Attach the UMP (see "Attaching The UMP" on page 13.
4. Measure the distance from the bottom of the tank to the sealing surface on the manifold.
5. Uncoil pigtail and lay flat so it will feed into the packer without knotting or kinking.
6. Loosen the clinch assembly starting by unscrewing the set screw in the side of locking nut, then backing off
the locking nut (see Figure 10 on page 16).
A slight twisting of the UMP will loosen the seals and facilitate adjusting it to the correct
length.
Do not rotate piping beyond 1/4 turn.
7. Pull the UMP end until the distance between the packer o-ring seal and the bottom of the UMP is 5 inches
(125 mm) (14 inches [356 mm] for floating suction) shorter than the distance measured in Step 4.
If UMP is equipped with floating suction adapter, see "Recommended Floating Suction In-
stallation" on page 6.
Take care not to damage the pigtail. If pump is to be adjusted shorter, keep tension
on the pigtail to eliminate kinking.
8. Tighten the column pipe locking nut and torque to 150 ft-lb (200 N•m), then torque the set screw to 30 - 35
in-lb (3.5 - 4 N•m).
9. Attach tubing to barbed fitting, secure with clamp.
Return line should be installed on every application to reduce nuisance trips of electronic
tank monitoring.
10. Lay the siphon return line tubing beside the column pipe. Stop 1 - 3 inches (25 - 76 mm) above the discharge
head.
11. Secure the siphon return line tubing to the column pipe with tie straps. Locate the tie straps approximately 6
inches (152 mm) from packer, 6 inches from the discharge head, and in the middle of the tubing.
For fixed length pumps: If removed, install eyebolt plug, using an adequate amount
of fresh, UL classified for petroleum, non-setting thread sealant and torque to 50 ft-
lbs (70 N•m). Confirm that the lifting eyebolt is properly torqued to 10 ft-lbs (13.6
N•m) with a minimum of 6 full threads installed. Occasionally, eyebolts are removed
Disconnect, lock out, and tag power at the panel before servicing the
pump.
Installing a Replacement Extractable Pump
