4" Standard Pump Installation, Operation & Service Manual
after pump installation and corrosion may occur in the threaded areas of the wiring
compartment cover (eyebolt plug) and the eyebolt. If corrosion has occurred, the
cover and eyebolt should be replaced.
12. Utilize the lifting eyebolt to suspend the pump vertically and then install the pump into the manifold per Step
18.
13. Remove cover from wiring compartment.
14. Pull pigtail wires into wiring compartment.
15. Cut pigtail wires leaving approximately 8 inches (200 mm) hanging out of wiring compartment.
16. Strip insulation off all wires 3/8 inch (10 mm).
17. Using supplied wire nuts attach like colored pump pigtail wires to like colored electrical connector wires as
shown in Figure 37.
18. Install excess wire into wiring compartment. Replace wiring compartment cover. Torque to 35 ft-lb (50 N•m).
Thread sealant should not be used.
19. Install the pump into the manifold.
For fixed length pumps:
If removed, install eyebolt plug, using an adequate amount of fresh, UL classified for
petroleum, non-setting thread sealant and torque to 50 ft-lbs (70 N•m). Confirm that
the lifting eyebolt is properly torqued to 10 ft-lbs (13.6 N•m) with a minimum of 6 full
threads installed. Occasionally, eyebolts are removed after pump installation and
corrosion may occur in the threaded areas of the wiring compartment cover (eyebolt
plug) and the eyebolt. If corrosion has occurred, the cover and eyebolt should be
replaced.
20. Utilize the lifting eyebolt to suspend the pump vertically and then install the pump into the manifold.
Before replacing the extractable, make sure that the surfaces of the packer o-ring and the
discharge o-ring seals are clean.
21. Align the positioning dowels of the manifold with the holes in the packer.
22. Push the packer as far as possible against the manifold.
Figure 37. Wiring Schematic
43
Installing a Replacement Extractable Pump
