Parts Lists
Customer Service Number
After unpacking the equipment, please inspect the parts. Make sure all accessories are included and that no
damage occurred during shipping. Report any damage to the shipper immediately and inform a customer service
representative at 1-800-873-3313 of any equipment damage or missing parts.
Yoke Assembly and Conduit Box Parts
Item
(ref. Figure 38)
1
1
2
3
3
3
3
4
4
Table 8. Yoke Assembly and Conduit Box Parts List
Part No.
113-105-5 Connector - Male (2-wire)
113-555-5 Connector - Male (3-wire) (Not Shown)
072-492-1 Ring - Snap
313-015-5 Connector - Repair (2-wire) AG
313-021-5 Connector - Repair (3-wire) AG (Not Shown)
313-002-5 Connector - Repair (2-wire) Petro (Not Shown)
313-019-5 Connector - Repair (3-wire) Petro (Not Shown)
108-496-5 Conduit Box - Single Petro
108-549-5 Conduit Box - Single AG
Figure 38. Yoke Assembly And Conduit Box Part Identification
Description
45
Qty.
1
1
1
1
1
1
1
1
1
