Veeder-Root Red Jacket Quick-Set Installation, Operation And Service page 26

4" Standard Pump Installation, Operation & Service Manual
WARNING DI SCONNECT , LOCK OUT ,
AND TAG POW ER AT THE
OFF
POWER PANEL BEFORE
W I RI NG THE PUM P .
Capacitor
Dispenser
Optional solenoid valve
(76 volt amps. max
Figure 17. 230 Vac Remote Control Box With 110 VAC Coil And Cap - Model 880-045-5/880-046-5
Line starter
S1 S2 S3 M1 M2 M3 N L1 L2
O B R
Motor
21
Conduit Box Wiring
115 volt
25 watt
P
EXT
max.
PILOT
LIGHT
Pilot light
3 P.S.T. toggle
switch
Load center
208 or 230 volt
NOTICE
Make gr ound connect i on i n
accor dance wi t h l ocal codes.
L2 L1
N
830-3
