4" Standard Pump Installation, Operation & Service Manual
Item (Ref.
Figure 39 &
Figure 40) Part No.
072-718-1
12
072-542-1
13 144-183-5
13 144-184-5
14 323-001-5
14 323-002-5
Pump Parts
Table 9. Packer-Manifold Assembly Parts List
O-Ring - FKM (-443) PETRO
O-Ring - FKM (-443) AG
Kit - Check Valve & Spring PETRO
Kit - Check Valve & Spring AG
Functional Element Ass'y. PETRO
Functional Element Ass'y. AG
Figure 41. Pump Parts
48
Description
Pump Parts
DOM INT'L
1 1
1 1
1 1
1 1
1 1
1 1
