rally for approx. 1/2 hour, where the parts are out of reach of children.
CLEANING THE MIXING OR GRINDING SYSTEM
CAUTION: For cleaning the glass containers in the automatic dishwasher,
always ensure that the glass containers can not touch any other objects of china,
glass, or stoneware crockery during operation of the dishwasher. Otherwise, the
parts could crack or get chipped.
Note
You may clean the lid of the mixing jug, and sealing rings in an automatic dish-
washer.
The knives of the blade assemblies are very sharp. Always
WARNING:
handle with care to avoid injuries and damage. Do not touch the knives with your
hands. The glass containers (glass jug and grinding cup) may crack easily,
when handled carelessly. Do not expose the glass containers to extreme tem-
perature variations to avoid cracking. Do not fill any hot liquid into the glass
containers of the appliance. Do not immerse the glass containers in hot liquids.
Otherwise, the glass could crack! Do not use the glass containers any more, if
the glass is chipped, cracked or broken in any way.
USING THE SELF-CLEANING FEATURE
In many cases, the following cleaning method may be successful, when cleaning the
mixing jug immediately after usage. If you have processed sticky food containing a
lot of hard fibres or tendons, some residues of food may cling to the knives and stick
at the rim of the sealing surfaces. If there are still residues sticking to the surfaces,
you should disassemble the mixing system for cleaning (see: 'Thorough Cleaning
and Removing Stubborn Residues').
Important: You need to disassemble the grinding system for taking out your
food and should clean the parts of the grinding system always separately (see:
'Thorough Cleaning and Removing Stubborn Residues'). The following cleaning
method could lead to overpressure within the grinding cup and cause damage.
1. Immediately after usage, thoroughly rinse the interior of the used processing sys-
tem with lukewarm water.
2. Pour approx. 200 ml lukewarm dishwater into the used mixing jug (the knives
should be just covered). Close the lid. Leave the mixing jug soak for approx. 10
minutes.
122
3. Ensure that the mixing jug is leak-free and the exterior is completely dry. Ensure
that the appliance is switched off at the selection dial and at the power switch.
Then mount the glass jug onto the motor base (see: 'Assembling the Mixing Sys-
tem''). Then plug in the power plug.
4. Switch on the appliance at the power switch and turn the selection dial several
times on and off to agitate the motor in short pulses. Thereafter leave the appli-
ance operate continuously for another minute at speed level 5.
5. Switch off the appliance at the selection dial and at the power switch. Wait until
the motor stops, then unplug. Remove the mixing jug from the motor base (see:
‚Using the Mixing System / Removing the Mixing Jug After Operation'').
6. Pour out the dishwater and rinse the interior of the processing system with clear water.
Check, whether the mixing jug and the knives of the blade assembly are completely
clean and no residues of food (e.g. fibres, tendons) are sticking to the surfaces.
7. Clean the mixing jug and lid (including the ingredients cup, or scraper, if
required) in lukewarm dishwater using a soft brush. Then rinse with clear water.
8. Wipe dry all parts and leave dry naturally for approx. 1/2 hour, where the
parts are out of reach of children.
Tip: Most residues of food can be removed with this method. If the knives or
sealing surfaces of the mixing jug are not clean, you may repeat the above pro-
cedure or proceed according to the following section.
THOROUGH CLEANING AND REMOVING STUBBORN RESIDUES
Important: Only clean the grinding system according to the following instructions.
Do NOT use any hard or sharp-edged objects for cleaning any parts of the appli-
ance to avoid damage to the surfaces. Scratches in the sealing surfaces may cau-
se leakage.
Note
The mixing system may be cleaned via the self-cleaning feature (see above). Use
the instructions in this section, if there are any stubborn residues sticking to the sur-
faces. Nevertheless, you should perform this procedure regularly to keep the pro-
cessing systems hygienically clean and in good operational condition.
1. Empty the glass container completely. Then rinse the glass container thoroughly.
2. If required, turn the blade assembly counter-clockwise to unscrew it from the
glass container. Remove the sealing ring from the blade assembly. To get an
