Important: Ensure that the exterior of the juice collector is clean and dry, before
mounting it on the motor base to avoid that residues of food and liquids get into
the motor base and/or clog the safety interlocks.
2. Place the juice collector on the motor base with the juice spout facing to the
locking arm. Make the juice spout slide into the spout groove and the pulp gut-
tering into the pulp container. Ensure that the drip-stop of the juice spout is turned
to the open position: the dark bar at the stainless steel sleeve of the juice spout
will be facing towards you.
CAUTION: The knives of the juicing sieve are very sharp. Hold the juicing
sieve at the rim.
3. Insert the juicing sieve into the centre of the juice collector and press it down
without violence to lock it to the drive rotor. If required, turn the juicing sieve to
and fro to achieve the correct orientation before pressing it down.
4. With the pulp spout covering into the pulp container, place the juicer cover onto the
juice collector and press it down slightly without violence until it settles firmly on the
juice collector. There may be no gap between the juicer cover and the juice collector.
5. Carefully lift the locking arm up to the vertical closed position by pushing the
locking arm onto the support on the juicer cover until it tangibly engages. If atta-
ched correctly, the locking arm will be fixed in this position.
6. Place the juice jug under the juice spout. Then cover the juice jug with the desi-
gnated lid. The appliance is now ready for juicing.
Note
We recommend using the designated juice jug, because some juices may froth
and splash at the juice spout. In any case, by covering the juice jug with the
appropriate lid, you avoid that splashes will escape from the juice spout.
Tip: For juicing, you may place any sufficiently large jug, drinking glass or mug
under the juice spout. In this case, keep in mind that splashing could occur and
juices could run down at the exterior of the used vessel.
ASSEMBLING THE MIXING SYSTEM
CAUTION: Ensure not to tilt the thread when screwing on the blade assembly.
Otherwise, the thread could get damaged and your food will run out. Do not over-tighten
the thread. If in doubt, check the seal by pouring some water into the mixing jug.
96
WARNING: Always ensure that the mixing jug is undamaged, before
assembling the system. Splinters of glass could cause severe injuries and dama-
ge. Additionally, chipped edges or any dried on food at the thread and/or
sealing area of the processing container could cause leakage and damage the
blade assembly or sealing ring.
1. Select the required blade assembly (see: 'Selecting the Optimum Processing Sys-
tem' and 'Tips for Best Results').
2. Check, whether the mixing jug, sealing ring, and blade assembly are complete-
ly undamaged. Additionally, for getting a leak-free seal, the sealing surfaces
must be completely clean.
3. With the smooth side facing downwards, place the sealing ring into the blade
assembly. Ensure to insert the sealing ring into the appropriate groove at the
inner rim of the blade assembly.
4. Screw the blade assembly onto the mixing jug by turning the blade assembly
clockwise. The connection must be tight and leak-free.
5. Pour some water into the mixing jug for checking, if the seal is leak-free.
Note
If the motor does not start, when switching on and selecting a speed level, probab-
ly the safety interlocks are not engaged. These features of the appliance ensure
that the processing system is locked firmly to the motor base and probably leak-
free, thus protecting you from harm and damage. Check, if the threads are scre-
wed on sufficiently tight (see: 'Solving Problems').
ASSEMBLING THE GRINDING SYSTEM
In any case, the grinding system must be filled, before assembling the grinding
blades. The grinding cup will be closed air-tight, after screwing on the grinding
blades (see: 'Operation / Grinding Dry Food').
OPERATION
WARNING: Always ensure that the appliance and all its parts and accesso-
ries are out of reach of children. Handle the juicing sieve and blade assemblies
with special care, because the integrated knives are very sharp.
The glass containers are fragile. Always handle with care. Do not fill in any hot
food or liquids! Even small splinters and shards could cause severe injuries,
97
