Wipe dry the juicing sieve thoroughly – especially the drive coupling. Replace
the juicing sieve and push it down slightly onto the drive rotor. Then replace the
juicer cover. Lift the locking arm and push the locking arm into the support at the
juicer cover. Ensure to open the drip-stop (dark bar on the stainless steel sleeve
is facing towards you). Replace the juice jug.
8. Thereafter, you may continue juicing.
For blending runny, juicy food, the mixing system is suited best (see: 'Tips for Best
Results'). Depending on your type of food, you may fill the mixing jug from 250-350g
(solids; e.g. vegetables or fruit) to 1500 ml (1.5 litres; liquids, beverages and very
runny food).
Blending Runny Food or Chopping Solid Ingredients
The knives of the blade assemblies are very sharp. Only touch
WARNING:
the blade assembly by the collar. Always ensure that the mixing jug is completely clean
and undamaged. There may be no cracks and chipped edges. Even small splinters
could cause severe injuries when getting into your food or beverages. Additionally,
chipped edges or any dried on food at the thread and/or sealing area of the mixing
jug or sealing ring could cause leakage and damage to the blade assembly.
Before mounting the processing system onto the motor base, always ensure that
the exterior of the used system (especially the bottom of the blade assembly) is
completely clean and dry to avoid risk of electric shock and damage due to liquid
getting into the motor base.
CAUTION: Do not attempt to operate the appliance without closing the mixing jug
with the appropriate lid, to avoid that your food will be hurled out of the mixing jug.
Additionally, you should always keep one hand on the lid while the motor is agitating.
Important: When working with the mixing system, you may (and, in most cases,
should) add some liquid (water, juice, gravy, or stock). Ensure to hold the mixing
jug level, when it is filled to avoid overflow.
Tip: You may interchange the blade assemblies. By selecting the optimum blade assem-
bly, the results can be adapted to your liking (see: 'Tips for Best Results'). However, in
most cases the dedicated blade assembly (mixing blades) is the best selection.
1. Prepare your food: remove all inedible parts (e.g. stalks, bitter or hard shells,
seeds). Then cut large parts into cubes of approx. 2cm in size.
2. Select the required blade assembly (see: 'Selecting the Optimum Processing System').
102
3. If required, assemble the mixing system (see: 'Assembling the Mixing Jugs'). Use
some water for checking if the system is leak-free.
Note
Because it is not mandatory to disassemble the mixing jug for cleaning after usa-
ge, the mixing jug could still be ready for filling it. However, you should check the
mixing jug for leakage by pouring in some water.
4. Fill the mixing jug with the first portion of your prepared food. Add any additionally
required ingredients according to your recipe (e.g. herbs and spices). Always observe
the maximum total amount (including all ingredients) for the used processing system.
Mixing system: 1500 ml (uppermost grading line of the mixing jug).
Note
If you wish to process larger amounts, split up your food into portions.
5. Close the mixing jug with the appropriate lid. Insert the ingredients cup and turn
the ingredients cup clockwise to lock it into the mixer lid. Otherwise, the ingre-
dients cup could fall out during operation.
6. Ensure that the exterior of the mixing system is completely dry. Place the mixing sys-
tem onto the motor base. If required, turn the mixing system to and fro until it settles
down easily on the drive rotor and achieves a stable stand on the motor base.
CAUTION: For mounting or dismounting the mixing system at the motor base,
do not grasp the mixing jug. Always grasp the collar of the blade assembly to
avoid damage to the thread connecting the mixing jug and blade assembly. Addi-
tionally, the connection could get over-tightened, making it extremely difficulty to
remove the blade assembly after operation.
7. Grasp the blade assembly with both hands by the collar and turn it clockwise
for fixing it to the motor base (turn it a little more than a finger's breadth after
feeling the first resistance). The appliance is now ready for operation.
CAUTION:
Please keep in mind that the motor will start operation immediate-
ly, when connecting the appliance to the power supply, with the power switch and
selection dial in operating position. Thus, always switch the power switch to "O"
and selection dial to "OFF", before plugging in the power plug.
8. Ensure that the selection dial and power switch are turned to the "OFF" position.
Then insert the power plug into an appropriate wall power outlet (see: 'Important
Safeguards for Electrical Appliances').
