2-22 Setup and Operation

Using Keys

The following table lists Setup keys and their functions.
Key
PgUp/PgDn
Tab
Esc
F3/F4

Checking/Setting System Parameters

See the following table for a list of parameters, their factory default settings, and alternate
settings. A description of each setting follows the table.
To reset all parameters to the default settings, select Auto Configuration with Defaults from
the Setup Main Menu and press Y.
Parameter
Standard CMOS Setup
System Date
System Time
Diskette Drive A: **
Diskette Drive B: *
Internal Hard Disk Drive
Int Master
Table 2-5 Setup Key Functions
What It Does
Moves the cursor between the displayed parameters.
Modifies the current parameter settings.
For some parameter settings, moves the cursor
between the subfields. For example, for System Time,
Tab moves the cursor from hour to minute to second.
In the Main Menu screen, press Esc to display the "Quit
without saving" prompt. Also, press Esc to exit Setup
menus, and return to the Main Menu.
Changes the screen color.
Table 2-6 Setup Parameters
Default Setting
mm/dd/yyyy
hh:mm:ss
1.44MB, 3 1/2"
Not Installed
Enabled
Auto
Alternate Setting(s)
Not Installed
1.2 MB, 5 1/4"
1.44 MB, 3 1/2"
1.2 MB, 5 1/4"
1.44MB, 3 1/2"
Not Installed
Disabled
Enabled
Not Installed
BIOS Defined
User Defined
Auto
CD-ROM
LS-120
