NEC VERSA 6060 Service Manual page 106

Appendix B
Video Modes
The following tables list NEC Versa system video modes.
Table B-1
Mode Display
(Hex) Mode
0* Text
0** Text
0*** Text
1* Text
1** Text
1*** Text
2* Text
2** Text
2*** Text
3* Text
3** Text
3*** Text
4 Graphics
5* Graphics
5** Graphics
5*** Graphics
6 Graphics
*CGA
**EGA
***VGA
LCD Display Mode Setting (800x600 TFT Color
LCD and Simultaneous CRT Display)
Text
Colors Display
16 (gray) 40x25
16 (gray) 40x25
16 40x25
16 40x25
16 40x25
16 40x25
16 (gray) 80x25
16 (gray) 80x25
16 80x25
16 80x25
16 80x25
16 80x25
4 40x25
4 (gray) 40x25
4 (gray) 40x25
4 40x25
2 80x25
Pixel
Resolution Font
320x200 8x8
320x350 8x14
360x400 9x16
320x200 8x8
320x350 8x14
360x400 9x16
640x200 8x8
640x350 8x14
720x400 9x16
640x200 8x8
640x350 8x14
720x400 9x16
320x200 8x8
320x200 8x8
320x200 8x8
320x200 8x8
640x200 8x8
Video
Memory
(KB)
256
256
256
256
256
256
256
256
256
256
256
256
256
256
256
256
256
