1-2 Technical Information
HARDWARE OVERVIEW—FRONT
Take a moment to become familiar with the location and function of controls located on the
front of the system.

Liquid Crystal Display (LCD)

The LCD operates with NeoMagic NMG4 VGA controller. The controller supports XGA,
uses a 64-bit accelerator with a Peripheral Component Interconnect (PCI) interface.
The NEC Versa 6060 LCD features the following:
T
12.1-inch Thin Film Transistor (TFT) CCFT Super VGA (SVGA) single-backlite
color
T
0.306 mm dot pitch
T
16-bit digital interface
T
800 x 600 resolution
T
64K colors.
Additional LCD panel features:
T
Power LED that indicates the current power status. This LED is visible with the
LCD panel opened or closed.
T
Slide switch that adjusts screen brightness.
Table 1-1 Model Configurations
FEATURE NEC Versa 6060
CPU Intel Pentium® with
MMX Technology
P55CLM/166 MHz
On-Board DRAM 16-MB
Video Memory 2-MB included in
video chip
Hard Disk Drive 2.1 GB or 3.2 GB
CD-ROM Reader 20X CD ROM Reader
FDD or 3 ½" 1.44MB
SuperDisk LS-120 120MB
Color LCD 12.1" CCFT Super
VGA(SVGA),TFT
Color Display
