MESSAGE
Fixed disk
configuration error
C: drive error or
failure
Hard Disk controller
failure
Keyboard controller
failure
Keyboard Error
KB\interface error

SETUP UTILITY

The Setup utility is a ROM-based program. It is functional when enabled (factory default).
Setup automatically detects current system parameters during the power-on self-test
(POST), described in the previous section. It also provides the following functions:
Table 2-4 POST Error Messages
WHAT TO DO
Start Setup. Exit and save to update the
parameters. Check to see if the hard disk
connector is seated properly. If there is still a
problem, the hard disk might need repair.
Press F2 to start Setup. Exit and save to update
the parameters.
Check to see if the hard disk connector is
seated properly.
If there is still a problem, the hard disk might
need repair.
Press F2 to start Setup. Exit and save to update
the parameters.
Check to see if the hard disk connector is
seated properly.
The hard disk controller does not work and
might need repair.
Unplug external keyboard if attached and
reboot the system. If it still fails, have the
system repaired.
NOTE
Repeated keystrokes during boot may
produce an error message .
A timing problem exists with the keyboard. If
the error message remains, the keyboard may
have to be repaired.
Error exists in keyboard connector. If the error
message remains, the keyboard may have to
be repaired.
NOTE
If a display related error occurs it is indi-
cated by beeps. Display related errors usually re-
quire a system board replacement.
Setup and Operation 2-19
