Connector Locations and Pin Assignments
Table A-6 Parallel Printer Pin Assignments
Pin
Signal
13
Select
14
- Auto Feed XT
15
- Error
16
- Initialize
17
- Select In
18 -25
Ground
Table A-7 Power Connector
Pin
Signal
1
Ground
2
DCSYS
3
DCCHG
4
Type
Table A-8 Hard Disk Drive Connector
Pin
Signal
1
HDD Access LED
2
+5V
3
Chip Select 0
4
+5
Chip Select 1
5
+5V
6
Address 0
7
+5V
8
Address 2
9
10
+5V
11
Address 1
12
+5V
13
Diagnostic
14
Not Used
A-5
