Power Switch

Toggle the power switch button to ON after connected to the power source can turn it on,
toggle the button to OFF can turn it off. The anti-false touch function is available for setting
in the menu.

Mode Selection

Short press the MODE button to enter mode
selection interface, rotate and press the select
dial to choose among the following modes and
adjust the corresponding parameters. Rotate
the select dial upward to increase the values,
while rotate downward to decrease the values.
CCT Mode
Short press the MODE button to enter CCT
mode, in which you can adjust the DIM, CCT
and GM.
DIM Range：0％～ 100％
CCT Range：1800K ～ 10000K
GM Range：-100% ～ +100%
HSI Mode
Short press the MODE button to enter HSI
mode, in which you can adjust the DIM, HUE
and SAT.
DIM Range：0％～ 100％
HUE Range：0° ～ 360°
SAT Range：0% ～ 100%
MODE
CCT
RGBW
CCT
10000
HSI
60
HSI
XY
＞10h
K
＞10h
0
%
60
GEL
FX
DIM
CCT
GM
DIM
HUE
