Godox KNOWLED MS60R Instruction Manual page 54

Full-color led light

Power Adapter MS60PA01

1. Align the light body with the metal contacts at both ends of the power adapter, insert

the power adapter into the slot and press it down, the battery disassemble pusher will

automatically lock with a "click", and the power adapter is installed.

2. Press and hold the battery disassemble pusher, then pull the power adapter out to

disassemble it.

3. Connect the power adapter to power source via the built-in 8-shaped power socket to

power the light body.

8-shaped power socket

Pusher

USB-C output port

Hanging

Hole

Hanging Hole
