1. DMX
Short press the select dial to enter DMX
interface, rotate and press the select dial to
adjust the following settings.
Level 1 Option Level 2 Option
001-512
Address
01: CCT 8Bit
DMX Mode
02: HSI 8Bit
03: RGB 8Bit
04: RGBW 8Bit
05: X-Y 8Bit
06: CCT+HSI 8Bit
07: CCT+RGBW 8Bit
08: FX 8Bit
09: GEL 8Bit
10: CCT 16Bit
11: HSI 16Bit
12: RGB 16Bit
13: RGBW 16Bit
14: X-Y 16Bit
15: FX 16Bit
16: GEL 16Bit
17： ULTIMATE 8Bit
18： ULTIMATE 16Bit
On
RDM State
Off
Hold Last Command
DMX Lost
Black Out
Black Out After 2 min
On
Termination
Off
On
Extend DMX
Channels
Off
DMX
DMX Add
DMX Mode
RDM State
DMX Lost
Termination
Extend DMX Channels
Description
Initial address
CCT mode in 8bit
HSI mode in 8bit
RGB mode in 8bit
RGBW mode in 8bit
X-Y mode in 8bit
CCT+HSI mode in 8bit
CCT+RGBW mode in 8bit
FX mode in 8bit
GEL mode in 8bit
CCT mode in 16bit
HSI mode in 16bit
RGB mode in 16bit
RGBW mode in 16bit
X-Y mode in 16bit
FX mode in 16bit
GEL mode in 16bit
ULTIMATE DMX mode in 8bit
ULTIMATE DMX mode in 16bit
Turn on RDM, the controller can set the fixture address and DMX mode
Turn off RDM
After the DMX control signal is lost, continue to use the last received
DMX control signal until power down or a valid DMX control signal is
received again.
The light is off immediately.
After the DMX control signal is lost, continue to use the last received
DMX control signal for 2 minutes then black out.
Note: If a valid DMX control signal is received within 2 minutes, then
use the new DMX control signal.
Turn on DMX terminal
Turn off DMX terminal
Turn on extend DMX channels
Turn off extend DMX channels
66
60
1
01
On
