Godox KNOWLED MS60R Instruction Manual page 63

FX Mode
Short press the MODE button to enter FX
mode, in which you can choose among the
following 11 effects and adjust their respective
parameters. Rotate the select dial upward
to increase the parameters, while rotate
downward to decrease the parameters.
1. Flash
This light effect simulates the flash of a camera flash or a traditional flash bulb, often used
to create a lively and dynamic atmosphere.
SW (switch): Turn on/off the effect
DIM: 0％ -100％ (in 0.1% increment)
Color: CCT/HSI
CCT/HUE：1800K-10000K/0-360°
SPD (speed): 1-100
MOD (mode): Camera Flash/Flash Bulb
TRIG (trigger): Auto/Manual
2. Lightning
This effect simulates the natural thunder and lightning and is often used to create a tense,
terrifying or mysterious atmosphere.
SW (switch): Turn on/off the effect
DIM: 0％ -100％ (in 0.1% increment)
CCT: 1800K-10000K
Times: Random/1-10
FREQ (frequency): Random /2-20
TRIG (trigger): Auto/Manual
Flash
62
60
