Jumper settings on the IDE device must be set to the master
or slave device (see the documentation that comes with the
device).
IDE Device Configuration Submenu
The Hard Disk Submenu lets you check or change the
following hard disk drive parameters.
T
IDE Device Configuration
T
IDE Translation Mode
T
Multiple Sector Setting
T
Fast Programmed I/O Modes
IDE Device Configuration
The system is shipped with default as "Auto Configured"
selected in this submenu. The system then automatically
detects the hard disk type and sets the remaining
parameters.
If your IDE hard disk does not feature auto IDE type
detection or your IDE hard disk was formatted on another
system with parameters different than those reported by the
drive, you need to select "User Definable," and set the
"Number of Cylinders," "Number of Heads," "Number of
Sectors," and Maximum Capacity."
Number of Cylinders
Number of Heads
Number of Sectors
Maximum Capacity
NEC Drivers and Utilities 4-7
