BIOS Recovery
Recovery Mode
Normal Operation
(default)
6.
Replace the system unit cover (see "Replacing the
System Unit Cover" in Chapter 5).
7.
Connect system power cables and monitor.
Power on the system. The system displays a system
8.
configuration error message.
9.
Power off, unplug the system and monitor, and remove
the cover.
10.
Remove the jumper block from pins 2-4 and replace it
on pins 4-6.
11.
If you removed any expansion boards, replace them
(see "Replacing Expansion Boards" in Chapter 5).
12.
Replace the system unit cover. Reconnect the system
power cables and peripheral devices.
13.
Power on the system.
14.
Run Setup (see Chapter 4, NEC Drivers and Utilities).
6-6 Setting System Board Jumpers
Jumpers
1
2
2-4
5
6
9
10
1
2
4-6
5
6
9
10
BIOS Recovery Jumper
