All-Rounder 20 in 1
Removing
Perform the steps for inserting the drive
shaft in the reverse order:
1. Hold the drive shaft firmly with one
hand.
2. Turn the mixing bowl upside down
and unscrew the wing nuts.
3. Pull the drive shaft out of the mixing
bowl.
Mixing Bowl
The mixing bowl (15) is where the items
to be mixed or cooked are processed and
heated.
Please Note!
■
The contacts on the bottom of the
mixing bowl need to be clean and dry.
■
If the mixing bowl is closed with one
of the lids or the steaming attach-
ment, it cannot be removed from the
main unit.
• Inserting: Place the mixing bowl in the
main device (14) (Picture F). When you
do this, the contacts on the bottom of
the mixing bowl must be plugged into
the socket (21) of the main device.
• Removing: If the lid (3, 7) or the
steaming attachment (17) is attached,
take it off. Then pull the mixing bowl
out of the main device.
Inserts
Please Note!
■
Never hold the cross-blade insert
firmly by the blades. Hold it by the
top end when inserting and removing
it. There is a danger of injury from
sharp blades.
(Picture G)
• The cutting-blade insert (5), stirring
insert (2) and whisk insert (1) are
plugged directly onto the drive shaft.
09946_Inlay_de-en-fr-nl_A5_V2.indb 35 09946_Inlay_de-en-fr-nl_A5_V2.indb 35
• For the cutting attachment (10), the
shaft extension (11) is required. Plug it
onto the drive shaft. Plug the cutting
attachment onto the shaft extension.
Please Note: The side with a long
blade is intended for slicing, the side
with several small blades is intend-
ed for grating. The side you want
must be pointing upwards when it is
inserted.
• To remove the insert, simply pull it up
and out. The cutting attachment has
two round holes to make it easier to
grip.
• The basket insert (8) is placed in the
mixing bowl. To remove it, place the
bottom of the measuring cup (13)
on the middle of the insert until it
fits securely, and pull out the insert
(Picture H).
Lid and Steaming Attachment
The items supplied include two lids for
the mixing bowl (15):
• lid with a feed chute (7), for use with
the cutting attachment (10), and
• lid with seal cap (3) for use with the
rest of the inserts.
For steaming, the steaming attach-
ment (17) is attached to the mixing bowl
instead of a lid.
To ensure that the items being mixed or
cooked do not splash out, the device can
only be operated if one of the lids or the
steaming attachment has been attached
and locked in place. Both lids and the
steaming attachment are inserted and
removed again in the same way.
Inserting
1. Make sure that the sealing ring has
been inserted in the groove on the
bottom of the lid or steaming at-
tachment, is clean and undamaged
so that it is sealed tight.
2. Place the lid or steaming attachment
on the mixing bowl and press it down
as far as it will go (Picture I).
