4-18 Troubleshooting and Repair

DISASSEMBLY AND REASSEMBLY

This subsection contains step-by-step disassembly procedures for the Image P90E and
Image P100E computers. The hard disk drive, 3 1/2-inch diskette drive, and CD-ROM
reader are installed and included in these disassembly procedures. Reassembly is the
reverse of disassembly. Each procedure is supported by a simplified disassembly
illustration to facilitate removal. The detailed exploded-view diagram and parts lists for the
system is shown later in this section.
A Phillips-head screwdriver is the only required tool. For complete disassembly of the
system unit, follow the disassembly order listed in Table Section 4-5. To reassemble,
follow the table in reverse order.
Individual removal procedures do not require the total disassembly of the computer. Each
of the following subsections lists the parts that must be removed before beginning the
removal procedure. To reassemble, follow the procedure in reverse order.
Table Section 4-5 Image P90/P100E Disassembly Sequence
Sequence Part
1 Top cover
2 Expansion board(s)
3 Front panel assembly
4 Power button cover
5 Slot cover and metal cover plate
6 Speaker assembly
7 Memory expansion board
8 5 1/4-inch device cage
9 5 1/4-inch device
10 3 1/2-inch hard disk drive
11 3 1/2-inch diskette drive
12 Power supply
13 Real-time clock battery
14 System board
See Page
4-19
4-21
4-22
4-23
4-24
4-26
4-27
4-29
4-30
4-31
4-33
4-35
4-36
4-37
