Icom IC-7760 Reference Manual page 9

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Connectors
01 19 00 00 ~ 02 55 ACC AF/IF Output >
01 20 00/01
01 21 00/01
01 22 00 00 ~ 02 55 ACC AF/IF Output >
01 23 00/01
01 24 00/01
01 25 00 00 ~ 02 55 MOD Input >
01 26 00 00 ~ 02 55 MOD Input >
01 27 00 00 ~ 02 55 MOD Input >
01 28 00 00 ~ 02 55 MOD Input >
01 29 00 ~ 09
01 30 00 ~ 09
01 31 00 ~ 09
01 32 00 ~ 09
Description
Send/read the AF Output Level setting
(00 00=0% ~ 02 55=100%)
ACC AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
ACC AF/IF Output >
Send/read the AF Beep/Speech���
Output setting
(00=OFF, 01=ON)
Send/read the IF Output Level setting
( 00 00=0% ~ 02 55=100%)
LAN AF/IF Output >
Send/read the Output Select setting
(00=AF, 01=IF)
LAN AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
Send/read the USB MOD Level setting
(00 00=0% ~ 02 55=100%)
Send/read the LINE-IN MOD Level
setting
(00 00=0% ~ 02 55=100%)
Send/read the ACC MOD Level setting
(00 00=0% ~ 02 55=100%)
Send/read the LAN MOD Level setting
(00 00=0% ~ 02 55=100%)
MOD Input >
Send/read the DATA OFF MOD setting
( 00=MIC, 01=USB, 02=LINE-IN,
03=ACC, 04=MIC, USB,
05=MIC, LINE-IN, 06=MIC, ACC,
07=MIC, USB, ACC,
08=MIC, LINE-IN, ACC, 09=LAN)
MOD Input >
Send/read the DATA1 MOD setting
( 00=MIC, 01=USB, 02=LINE-IN,
03=ACC, 04=MIC, USB,
05=MIC, LINE-IN, 06=MIC, ACC,
07=MIC, USB, ACC,
08=MIC, LINE-IN, ACC, 09=LAN)
MOD Input >
Send/read the DATA2 MOD setting
( 00=MIC, 01=USB, 02=LINE-IN,
03=ACC, 04=MIC, USB,
05=MIC, LINE-IN, 06=MIC, ACC,
07=MIC, USB, ACC,
08=MIC, LINE-IN, ACC, 09=LAN)
MOD Input >
Send/read the DATA3 MOD setting
( 00=MIC, 01=USB, 02=LINE-IN,
03=ACC, 04=MIC, USB,
05=MIC, LINE-IN, 06=MIC, ACC,
07=MIC, USB, ACC,
08=MIC, LINE-IN, ACC, 09=LAN)
Cmd� Sub cmd� Data
1A* 05 01 33 00 ~ 04
01 34 00 ~ 04
01 35 00 ~ 04
01 36 00/01
01 37 00/01
01 38 00/01
01 39 00/01
01 40 00/01
01 41 00/01
01 42 00 ~ 10
8
Description
USB SEND/Keying >
Send/read the USB SEND setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L USB (A) and USB (B) are the 2
virtual COM ports on the [USB B]
port on the controller's rear panel�
L You cannot select the same
setting for USB keying (CW) or
USB keying (RTTY)�
USB SEND/Keying >
Send/read the USB Keying (CW)
setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L USB (A) and USB (B) are the 2
virtual COM ports on the [USB B]
port on the controller's rear panel�
L You cannot select the same
setting for USB SEND�
USB SEND/Keying >
Send/read the USB Keying (RTTY)
setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L USB (A) and USB (B) are the 2
virtual COM ports on the [USB B]
port on the controller's rear panel�
L You cannot select the same
setting for USB SEND�
External Keypad >
Send/read the VOICE setting
(00=OFF, 01=ON)
External Keypad >
Send/read the KEYER setting
(00=OFF, 01=ON)
External Keypad >
Send/read the RTTY setting
(00=OFF, 01=ON)
External Keypad >
Send/read the PSK setting
(00=OFF, 01=ON)
Keyboard/Mouse >
Send/read the Keyboard [F1]-[F8]
(VOICE) setting
(00=OFF, 01=ON)
Keyboard/Mouse >
Send/read the Keyboard [F1]-[F8]
(KEYER) setting
(00=OFF, 01=ON)
Keyboard/Mouse >
Send/read the Keyboard Type setting
( 00=English, 01=Japanese,
02=United Kingdom, 03=French,
04=French (Canadian), 05=German,
06=Portuguese, 07=Portuguese
(Brazilian), 08=Spanish, 09=Spanish
(Latin American), 10=Italian)
