REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
00 See p� 16�
01 See p� 16�
02 See p� 16�
03 See p� 16�
04 See p� 16�
05 See p� 16�
06 See p� 16�
07 29
B0
B1
C0
C1
C2* 00/01
D0
D1
D2* 00
01
08
00 01 ~ 00 99 Select the Memory channel
01 00
01 01
09
0A
0B
0E 00
01
02
03
12
13
22
23
Ax
(x=1 ~ 7)
B0
B1
01 ~ 03
B2 00 ~ 03
D0
D3
0F 00/01
Description
Send the frequency data (transceive)
Send the mode data (transceive)
Read the band edge frequencies
Read the operating frequency
Read the operating mode
Set the operating frequency
Set the operating mode
Select the VFO mode
Exchange Main and Sub bands
Equalize Main and Sub bands
Turn OFF Dualwatch
Turn ON Dualwatch
Send/read the Dualwatch setting
(00=OFF, 01=ON)
Select the Main band
Select the Sub band
Send/read Main band selection
Send/read Sub band selection
Select the Memory mode
(00 01=M-CH01, 00 99=M-CH99)
Select program scan edge channel P1
Select program scan edge channel P2
Memory write
Memory copy to VFO
Memory clear
Cancel the scan
Start a Programmed/memory scan
Start a Programmed scan
Start a ∂F scan
Start a Fine programmed scan
Start a Fine ∂F scan
Start a Memory scan
Start a Select memory scan
Select ∂F scan span
( x=1 (±5kHz), x=2 (±10kHz),
x=3 (±20kHz), x=4 (±50kHz),
x=5 (±100kHz), x=6 (±500kHz),
x=7 (±1MHz))
Clear the Select channel setting
Set as select channel
L The previously set number by
CI-V is set after turning the
power ON, or "1" is selected if no
selection is performed�
Set the channel as a Select channel
(01=SEL1, 02=SEL2, 03=SEL3)
Set the Select memory scan channel
( 00=ALL, 01=SEL1, 02=SEL2,
03=SEL3)
Set Scan resume OFF
Set Scan resume ON (Close&Delay)
Read Split setting
(00=Split OFF, 01=Split ON)
Cmd� Sub cmd� Data
0F 00
01
10* 00 ~ 08
11* 00
29
03
06
09
12
15
18
21
24
27
30
33
36
39
42
45
2
12* 00* 00/01
29
2
01* 00/01
2
02* 00/01
2
03* 00/01
13 00
01
02
01 29
14* 00 00 ~ 02 55 Send/read the AF level
02 29
00 00 ~ 02 55 Send/read the RF gain level
03 29
00 00 ~ 02 55 Send/read the squelch level
05 29 00 00 ~ 02 55 Send/read the APF position
06 29
00 00 ~ 02 55 Send/read the NR level
07 29 00 00 ~ 02 55 Send/read [TWIN PBT] (PBT1) position
08 29 00 00 ~ 02 55 Send/read [TWIN PBT] (PBT2) position
3
Description
Set Split function OFF
Set Split function ON
Send/read the tuning step
( 00=OFF (10Hz or 1Hz)
01=100Hz, 02=1kHz, 03=5kHz,
04=9kHz, 05=10kHz, 6=12�5kHz,
07=20kHz, 08=25kHz)
Send/read attenuator OFF setting
Send/read 3 dB attenuator setting
Send/read 6 dB attenuator setting
Send/read 9 dB attenuator setting
Send/read 12 dB attenuator setting
Send/read 15 dB attenuator setting
Send/read 18 dB attenuator setting
Send/read 21 dB attenuator setting
Send/read 24 dB attenuator setting
Send/read 27 dB attenuator setting
Send/read 30 dB attenuator setting
Send/read 33 dB attenuator setting
Send/read 36 dB attenuator setting
Send/read 39 dB attenuator setting
Send/read 42 dB attenuator setting
Send/read 45 dB attenuator setting
Select/read ANT1 selection
(00=RX ANT OFF, 01=RX ANT ON)
Select/read ANT2 selection
(00=RX ANT OFF, 01=RX ANT ON)
Select/read ANT3 selection
(00=RX ANT OFF, 01=RX ANT ON)
Select/read ANT4 selection
(00=RX ANT OFF, 01=RX ANT ON)
Speak all data by the voice
synthesizer
(S meter level, frequency, and mode)
Speak the operating frequency and
S meter level by voice synthesizer
Speak the operating mode by voice
synthesizer
L The mode is announced after the
ongoing speech�
(00 00=Minimum ~ 02 55=Maximum)
(00 00=Minimum ~ 02 55=Maximum)
(00 00=Minimum ~ 02 55=Maximum)
(10 Hz steps)
( 00 00=Pitch–550 Hz, 01 28=Pitch,
02 55=Pitch+550 Hz)
(00 00=0% ~ 02 55=100%)
( 00 00=max� Counter Clockwise ~
01 28=center ~ 02 55=max� Clockwise)
( 00 00=max� Counter Clockwise ~
01 28=center ~ 02 55=max� Clockwise)
