Icom IC-7760 Reference Manual page 25

REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• Scope span settings
(in the Center mode and SCROLL-C mode Scope)
Command: 27 15
1 2 3 4
X X 0 0 X X X X 0 0 0 0
00: MAIN
01: SUB
• Scope Edge number settings
(in the Fixed mode and SCROLL-F mode Scope)
Command: 27 16
X X X X
00=MAIN
01=SUB
• Scope Hold settings
Command: 27 17
X X X X
00=MAIN
01=SUB
• Scope Reference level settings
Command: 27 19
X X X X X 0 X X
00=Main scope
01=Sub scope
Adjustable range: –30�0 dB ~ +10�0 dB
in 0�5 dB steps�
5 6
Span (kHz)
2500
5000
10000
25000
50000
100000
250000
500000
01=Edge 1
02=Edge 2
03=Edge 3
04=Edge 4
00=Hold OFF
01=Hold ON
00= + (plus)
01= – (minus)
• Scope Sweep speed settings
Command: 27 1A
2�5
5
10
25
50
• Scope VBW (Video Band Width) settings
100
Command: 27 1D
250
500
• Scope RBW (Resolution Band Width) settings
Command: 27 1F
24
X X X X
00=MAIN 00=FAST
01=SUB 01=MID
02=SLOW
X X X X
00=MAIN 00=Narrow
01=SUB 01=Wide
X X X X
00=MAIN 00=WIDE
01=SUB 01=MID
01=NAR
