REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1C 04* 00/01
1E 00
01 See p� 16�
02
03* See p� 16�
21* 00 See p� 22�
01 00/01
02 00/01
25* See p� 22�
26* See p� 22�
27* 00 See p� 23�
10 00/01
6
11* 00/01
SCOPE > MAIN/SUB
12 00/01
SCOPE > DUAL
13 00/01
SCOPE > CENT/FIX (Touch/Touch for 1 second)
14 See p� 23�
SCOPE > SPAN (Touch/Touch for 1 second)
15 See p� 24�
SCOPE > EDGE
16 See p� 24�
SCOPE > HOLD
17 See p� 24�
SCOPE > REF
19 See p� 24�
Description
Send/read the CI-V Output (for ANT)
setting
(00=OFF, 01=ON)
Read number of available TX
frequency band
Read TX band edge frequencies
Read number of user-set TX
frequency band
Send/read user-set TX band edge
frequencies
Send/read the RIT/∂TX frequency
Send/read the RIT setting
(00=OFF, 01=ON)
Send/read the ∂TX setting
(00=OFF, 01=ON)
Send/read the Main or Sub band
frequency
Send/read the operating mode and
filter settings (for both Main and Sub
bands)
Read the Scope waveform data
( Only when "Scope ON/OFF status"
(Command: 27 10) and "Scope wave
data output" (Command: 27 11) are
set to "ON," outputs the waveform
data to the controller�)
Send/read the Scope ON/OFF status
(00=OFF, 01=ON)
Send/read the Scope wave data
output setting
(00=OFF, 01=ON)
Send/read the Main or Sub scope
setting
(00=Main, 01=Sub)
Send/read the Single/Dual scope
setting
(00=Single, 01=Dual)
Scope Center mode, Fixed mode,
SCROLL-C mode, or SCROLL-F
mode setting
Send/read the Span setting in the
Center mode or SCROLL-C mode
Scope
Send/read the Scope Edge Number
setting in the Fixed mode or
SCROLL-F mode
Send/read the Scope Hold function
ON/OFF status
Send/read the Scope Reference
level setting
Cmd� Sub cmd� Data
27* SCOPE > SPEED
1A See p� 24�
SCOPE SET: SCOPE > EXPD/SET (Touch for 1 second)
1B 00/01
1C 00 ~ 02
SCOPE > VBW
1D See p� 24�
SCOPE > EXPD/SET (Touch for 1 second) > Fixed Edges
1E See p� 25�
SCOPE > RBW
1F See p� 24�
SCOPE SET: SCOPE > EXPD/SET (Touch for 1 second)
20 00/01
28 00 00 ~ 08
29 00 or 01 +
Supported
commands
See p� 25�
*(Asterisk) Send/read data
29 Command 29 supported�
1
* 1A 05 01 63, 1A 08, 1A 0A, and 1A 0D cannot be sent�
2
* If the Antenna Type is set to "RX-I/O," command "01 (RX ANT ON)" is
invalid and "00 (RX ANT OFF)" is always returned�
3
* If the Antenna Type is set to "RX-ANT," command "01 (ON)" is invalid
and "00 (OFF)" is always returned�
4
* In the CW mode, if the transceiver transmits or the Break-in function
is ON, a message will be transmitted as CW code when you send it
from your PC�
5
* Sending the power ON command (18 01) turns ON the transceiver
when the [USB B] port on the controller's rear panel is connected to
the PC and the transceiver is OFF (Standby/Shutdown)�
L When the transceiver is remotely controlled through the [REMOTE]
jack on the RF deck's rear panel, the transceiver is not turned ON
even if the command is sent�
6 Valid only when the [REMOTE] jack on the RF deck's rear panel or
*
the [USB B] port on the controller's rear panel is connected�
15
Description
Send/read the Scope Sweep speed
setting
Send/read the Scope during Tx
(CENTER TYPE) setting
(00=OFF, 01=ON)
Send/read the CENTER Type Display
setting
( 00=Filter Center,
01=Carrier Point Center,
02=Carrier Point Center (Abs� Freq�))
Send/read the Scope VBW setting
Send/read the Scope Fixed Edge
frequencies
Send/read the Scope RBW setting
Send/read Marker Position
(FIX Type/SCROLL Type) setting
(00=Filter Center, 01=Carrier Point)
Transmit the Voice TX Memory
(00=Stop, 01=T1 ~ 08=T8)
Regardless of active/inactive the
Main or Sub band, you can directly
specify the Main or Sub band, and
send/read the supported command
settings�
(00=MAIN, 01=SUB)
