Icom IC-7760 Reference Manual page 8

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Function
00 81 00/01
00 82 00/01
00 83 00 ~ 02
00 84 00 ~ 02
00 85 00/01
00 86 00/01
00 87 00/01
SET > Function > Front Key Customize
00 88 See p� 20�
00 89 See p� 20�
SET > Function > MIC Key Customize
00 90 See p� 20�
00 91 See p� 20�
SET > Function
00 92 00/01
00 93 00 ~ 02
00 94 00/01
00 95 00/01
00 96 00/01
00 97 00/01
00 98 00/01
00 99 00 00 ~ 05 11 Send/read the REF Adjust setting
SET > Connectors
01 00 00 ~ 30
Description
Send/read the MIC Up/Down Speed
setting
( 00=LOW, 01=HIGH)
Send/read the Quick RIT/∂TX Clear
setting
(00=OFF, 01=ON)
Send/read the [NOTCH] Switch (SSB)
setting
(00=Auto, 01=Manual, 02=Auto/Manual)
Send/read the [NOTCH] Switch (AM)
setting
(00=Auto, 01=Manual, 02=Auto/Manual)
Send/read the FILTER Screen
MAIN/SUB Select setting
( 00=Fix, 01=Auto (by FILTER, PBT
Operation))
Send/read the SSB/CW
Synchronous Tuning setting
(00=OFF, 01=ON)
Send/read the CW Normal Side
setting
(00=LSB, 01=USB)
Send/read the [VOX/BK-IN] Key
setting
Send/read the [AUTOTUNE] Key
setting
Send/read the [UP] Key setting
Send/read the [DN] Key setting
Send/read the Screen Keyboard
Type setting
(00=Ten-key, 01=Full Keyboard)
Send/read the Screen Full Keyboard
Layout setting
( 00=English, 01=German, 02=French)
Send/read the Screen Capture
[POWER] Switch setting
(00=OFF, 01=ON)
Send/read the Screen Capture
Keyboard [Print Screen] setting
(00=OFF, 01=ON)
Send/read the Screen Capture
Storage Media setting
(00=SD Card, 01=USB flash drive)
Send/read the Screen Capture File
Type setting
(00=PNG, 01=BMP)
Send/read the Calibration Marker
setting
(00=OFF, 01=ON)
(00 00=0%, 05 11=100%)
Phones >
Send/read the Level setting
(00=–15 dB ~ 30=+15 dB)
Cmd� Sub cmd� Data
1A* 05 01 01 00/01
01 02 00 00 ~ 02 55 Phones >
01 03 00/01
01 04 00/01
01 05 00 00 ~ 02 55 USB AF/IF Output >
01 06 00/01
01 07 00/01
00 00 ~ 02 55 USB AF/IF Output >
01 08
01 09 00/01
01 10 00/01
01 11 00/01
01 12 00 00 ~ 02 55 LINE-OUT AF/IF Output >
01 13 00/01
01 14 00/01
01 15 00 00 ~ 02 55 LINE-OUT AF/IF Output >
01 16 00/01
01 17 00/01
01 18 00/01
7
Description
Phones >
Send/read the L/R Mix setting
(00=OFF, 01=ON)
Send/read the Phone L/R Mix Level
setting
(00 00=0% ~ 02 55=100%)
USB AF/IF Output >
Send/read the Output Select setting
(00=AF, 01=IF)
USB AF/IF Output >
Send/read the AF/IF XFC Output
(SPLIT ON) setting
(00=MAIN, 01=SUB)
Send/read the AF Output Level setting
(00 00=0% ~ 02 55=100%)
USB AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
USB AF/IF Output >
Send/read the AF Beep/Speech���
Output setting
(00=OFF, 01=ON)
Send/read the IF Output Level setting
( 00 00=0% ~ 02 55=100%)
LINE-OUT AF/IF Output >
Send/read the AF Output Select setting
(00=MAIN, 01=SUB)
LINE-OUT AF/IF Output >
Send/read the Output Select setting
(00=AF, 01=IF)
LINE-OUT AF/IF Output >
Send/read the AF/IF XFC Output
(SPLIT ON) setting
(00=MAIN, 01=SUB)
Send/read the AF Output Level setting
(00 00=0% ~ 02 55=100%)
LINE-OUT AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
LINE-OUT AF/IF Output >
Send/read the AF Beep/Speech���
Output setting
(00=OFF, 01=ON)
Send/read the IF Output Level setting
( 00 00=0% ~ 02 55=100%)
ACC AF/IF Output >
Send/read the AF/SQL Output
Select setting
(00=MAIN, 01=SUB)
ACC AF/IF Output >
Send/read the Output Select setting
(00=AF, 01=IF)
ACC AF/IF Output >
Send/read the AF/IF XFC Output
(SPLIT ON) setting
(00=MAIN, 01=SUB)
