REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SCOPE > EXPD/SET (Touch for 1 second) > Fixed Edges
02 50 See p� 21�
02 51 See p� 21�
02 52 See p� 21�
02 53 See p� 21�
02 54 See p� 21�
02 55 See p� 21�
02 56 See p� 21�
02 57 See p� 21�
02 58 See p� 21�
02 59 See p� 21�
02 60 See p� 21�
02 61 See p� 21�
02 62 See p� 21�
02 63 See p� 21�
02 64 See p� 21�
02 65 See p� 21�
02 66 See p� 21�
02 67 See p� 21�
02 68 See p� 21�
02 69 See p� 21�
02 70 See p� 21�
02 71 See p� 21�
AUDIO SCOPE SET: AUDIO > SET
02 72 00/01
02 73 See p� 21�
02 74 00/01
02 75 See p� 21�
Description
15�00 – 20�00 >
Send/read the No�3 setting
15�00 – 20�00 >
Send/read the No�4 setting
20�00 – 22�00 >
Send/read the No�1 setting
20�00 – 22�00 >
Send/read the No�2 setting
20�00 – 22�00 >
Send/read the No�3 setting
20�00 – 22�00 >
Send/read the No�4 setting
22�00 – 26�00 >
Send/read the No�1 setting
22�00 – 26�00 >
Send/read the No�2 setting
22�00 – 26�00 >
Send/read the No�3 setting
22�00 – 26�00 >
Send/read the No�4 setting
26�00 – 30�00 >
Send/read the No�1 setting
26�00 – 30�00 >
Send/read the No�2 setting
26�00 – 30�00 >
Send/read the No�3 setting
26�00 – 30�00 >
Send/read the No�4 setting
30�00 – 45�00 >
Send/read the No�1 setting
30�00 – 45�00 >
Send/read the No�2 setting
30�00 – 45�00 >
Send/read the No�3 setting
30�00 – 45�00 >
Send/read the No�4 setting
45�00 – 60�00 >
Send/read the No�1 setting
45�00 – 60�00 >
Send/read the No�2 setting
45�00 – 60�00 >
Send/read the No�3 setting
45�00 – 60�00 >
Send/read the No�4 setting
Send/read the FFT Scope
Waveform Type setting
(00=Line, 01=Fill)
Send/read the FFT Scope
Waveform Color setting
Send/read the FFT Scope Waterfall
Display setting
(00=OFF, 01=ON)
Send/read the Oscilloscope
Waveform Color setting
Cmd� Sub cmd� Data
1A* 05 KEYER 001: KEYER > EDIT/SET > 001 SET
02 76 00 ~ 04
02 77 00/01
02 78 00/01
02 79 00/01
02 80 00/01
02 81 00/01
02 82 00/01
02 83 00/01
02 84 00/01
02 85 00 01 ~ 99 99 Send/read the Present Number setting
SET > CW-KEY Set
02 86 00 00 ~ 02 55 Send/read the Side Tone Level setting
02 87 00/01
02 88 01 ~ 60
02 89 28 ~ 45
02 90 00 ~ 03
02 91 00/01
02 92 00 ~ 02
02 93 00/01
RTTY DECODE SET: DECODE > <MENU1> > SET
02 94 00 ~ 03
02 95 See p� 21�
02 96 00/01
12
Description
Send/read the Number Style setting
( 00=Normal, 01=190→ANO,
02=190→ANT, 03=90→NO,
04=90→NT)
Send/read the Count Up Trigger (M1)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M2)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M3)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M4)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M5)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M6)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M7)
setting
(00=OFF, 01=ON)
Send/read the Count Up Trigger (M8)
setting
(00=OFF, 01=ON)
(00 01=1 ~ 99 99=9999)
(00 00=0% ~ 02 55=100%)
Send/read the Side Tone Level Limit
setting
(00=OFF, 01=ON)
Send/read the Keyer Repeat time
setting
(01=1 sec� ~ 60=60 sec�)
Send/read the Dot/Dash Ratio setting
(28=1:1:2�8 ~ 45=1:1:4�5; 0�1 steps)
Send/read the Rise Time setting
( 00=2 msec�, 01=4 msec�,
02=6 msec�, 03=8 msec�)
Send/read the Paddle Polarity setting
(00=Normal, 01=Reverse)
Send/read the Key Type setting
(00=Straight, 01=Bug, 02=Paddle)
Send/read the MIC Up/Down Keyer
setting
(00=OFF, 01=ON)
Send/read the FFT Scope Averaging
setting
(00=OFF, 01=2, 02=3, 03=4)
Send/read the FFT Scope
Waveform Color setting
Send/read the Decode USOS setting
(00=OFF, 01=ON)
