Icom IC-7760 Reference Manual page 10

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Connectors
01 43 00 10 ~ 01 00 Keyboard/Mouse >
01 44 00 ~ 31
01 45 00 ~ 02
01 46 00/01
01 47 00/01
01 48 00 ~ 02
01 49 00/01
01 50 00/01
01 51 00 00 ~ 02 23 CI-V >
01 52 00/01
01 53 00/01
01 54 00/01
01 55 00/01
01 56 00/01
01 57 00 ~ 02
Description
Send/read the Keyboard Repeat
Delay setting
( 00 10=100 msec� ~
01 00=1000 msec� (in 50 msec� steps))
Keyboard/Mouse >
Send/read the Keyboard Repeat
Rate setting
(00=2�0 cps ~ 31=30�0 cps)
Keyboard/Mouse >
Send/read the Mouse Pointer Speed
setting
(00=Slow, 01=Mid, 02=Fast)
Keyboard/Mouse >
Send/read the Mouse Pointer
Acceleration setting
(00=OFF, 01=ON)
USB DIAL >
Send/read the USB DIAL Select setting
(00=Only Sub, 01=Main/Sub)
USB DIAL >
Send/read the USB DIAL Auto TS
setting
(00=OFF, 01=Low, 02=High)
USB DIAL >
Send/read the USB DIAL
[TRANSMIT] Switch setting
( 00=Push to toggle,
01=Hold down to transmit)
CI-V >
Send/read the CI-V Transceive
Switch setting
(00=OFF, 01=ON)
Send/read the CI-V USB/LAN→
REMOTE Transceive Address setting
(00 00=00h ~ 02 23=DFh)
(in Hexadecimal)
CI-V >
Send/read the CI-V Output (for ANT)
setting
(00=OFF, 01=ON)
CI-V >
Send/read the CI-V USB (A) Echo
Back setting
(00=OFF, 01=ON)
CI-V >
Send/read the CI-V USB (B) Echo
Back setting
(00=OFF, 01=ON)
CI-V >
Send/read the USB (B) Function
setting
(00=RTTY/PSK Decode, 01=CI-V)
Send/read the SEND Relay Type
setting
(00=Reed, 01=MOS-FET)
Send/read the ACC BAND Voltage
Output setting
(00=MAIN, 01=SUB, 02=TX)
Cmd� Sub cmd� Data
1A* 05 01 58 00/01
01 59 00/01
01 60 00/01
SET > Network
01 61 00/01
01 62 See p� 20�
1
01 63* See p� 20�
01 64 See p� 20�
01 65 See p� 20�
01 66 01 ~ 30
01 67 See p� 20�
9
Description
Send/read the MIC Input DC Bias
setting
(00=OFF, 01=ON)
Send/read the PTT Port Function
setting
( 00=PTT Input,
01=PTT Input + SEND Output)
Send/read the REF IN setting
(00=IN, 01=OFF)
Send/read the DHCP (valid after
restart) setting
(00=OFF, 01=ON)
Send/read the IP Address (LAN)
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
L You cannot set the same address
as "IP Address (Controller)," "IP
Address (RF Deck)," and "Default
Gateway�"
Read the IP address obtained through
the DHCP (valid after restart) setting�
L When the DHCP (valid after
restart) is set to OFF, the manually
set IP address (LAN) is returned�
Send/read the IP Address (Controller)
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
L You cannot set the same address
as "IP Address (LAN)," "IP Address
(RF Deck)," and "Default Gateway�"
Send/read the IP Address (RF Deck)
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
L You cannot set the same
address as "IP Address (LAN),"
"IP Address (Controller)," and
"Default Gateway�"
L When the RF deck and the
controller are connected between
different segments, set the
address to 1A 05 01 72�
Send/read the Subnet Mask (valid
after restart) setting
( 01=128�0�0�0 (1 bit) ~
30=255�255�255�252 (30 bit))
L Valid when the DHCP (valid after
restart) is set to OFF�
Send/read the Default Gateway
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
L You cannot set the same address
as "IP Address (LAN)�"
L When the RF deck and the
controller are connected between
different segments, set the
address to 1A 05 01 74�
