REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• Keyer memory character entries
Command: 1A 02
- Character codes
Character ASCII code
0 ~ 9 30 ~ 39
A ~ Z 41 ~ 5A
Space 20
/ 2F
? 3F
, 2C
� 2E
@ 40
5E
^
* 2A
L Information
• Spaces after the end of the sentence are not necessary�
• To clear the Keyer memory contents, send one or more
spaces�
• Keyer memory content
Command: 1A 02
X X X ...... X X
X
2 ~ 71: Text data
1: Channel data
01=M1
02=M2
03=M3
04=M4
• IF filter width settings
Command: 1A 03
Mode Data
SSB/CW/
00 ~ 09
RTTY/PSK
SSB/CW/PSK 10 ~ 40
RTTY 10 ~ 31
AM 00 ~ 49
Description
Numbers
Letters
Word space
Symbol
Symbol
Symbol
Symbol
Symbol
Example: to send ,
BT
enter "5E 42 54"
Inserts the contest number
05=M5
06=M6
07=M7
08=M8
Steps
50 ~ 500 Hz (50 Hz)
600 Hz ~ 3�6 kHz (100 Hz)
600 Hz ~ 2�7 kHz (100 Hz)
200 Hz ~ 10�0 kHz (200 Hz)
• AGC time constant settings
Command: 1A 04
AGC time constant (sec�)
Data
SSB/CW/RTTY/PSK
00
01
02
03
04
05
06
07
08
09
10
11
12
13
• RX HPF/LPF settings for each operating mode
Command: 1A 05
X X X X
HPF (Lower edge)
00=Through
01 ~ 20=100 ~ 2000 Hz
L The value of the HPF should be smaller than the LPF�
• SSB/SSB-DATA transmission passband width
settings
Command: 1A 05
X X
Lower edge
Higher edge
19
AM
OFF OFF
0�1 0�3
0�2 0�5
0�3 0�8
0�5 1�2
0�8 1�6
1�2 2�0
1�6 2�5
2�0 3�0
2�5 4�0
3�0 5�0
4�0 6�0
5�0 7�0
6�0 8�0
00 01, 00 04, 00 07,
00 10, 00 11, 00 12
LPF(Upper edge)
05 ~ 24=500~2400 Hz
25=Through
00 15, 00 16, 00 17, 00 18
Lower edge Higher edge
0= 100 Hz 0= 2500 Hz
1= 120 Hz 1= 2700 Hz
2= 150 Hz 2= 2800 Hz
3= 200 Hz 3= 2900 Hz
4= 300 Hz
5= 500 Hz
