Icom IC-7760 Reference Manual page 17

REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• Operating frequency
Command: 00, 03, 05, 1C 03
1 2
X X X X X
• Operating mode
Command: 01, 04, 06
1 2
X X X X
1Operating mode
00 :LSB 05 :FM
01 :USB 07 :CW-R
02 :AM 08 :RTTY-R
03 :CW 12 :PSK
04 :RTTY 13 :PSK-R
L Filter setting (2) can be skipped with commands 01
and 06� In that case, "FIL1" is selected with command
01 and the default filter setting of the operating mode is
automatically selected with command 06�
3 4 5
X X X 0
2Filter setting
01 :FIL1
02 :FIL2
03 :FIL3
—
—
• Codes for CW message contents
Command: 17 (Up to 30 characters)
To send CW messages, use the following character
codes�
0
Character
0 ~ 9
A ~ Z
a ~ z
/
?
�
−
,
:
L "FF" stops sending CW messages�
L "^" is used to transmit a string of characters with no
inter-character space�
• Band edge frequency settings
Command: 02*, 1E 01, 1E 03
1 2 3
X X X X X X X X X X 0 0 2 D X X X X X X X X 0 0
Lower edge
* When obtaining the edge number (by command "02"), the
edge number (1) is not returned�
16
ASCII code Character
30 ~ 39 '
41 ~ 5A (
61 ~ 7A )
2F =
3F +
2E "
2D @
2C ^
3A Space
4 5 6 7 8 9
Higher edge
ASCII code
27
28
29
3D
2B
22
40
5E
20
10 11 12
